UTECO TOPAZ 608 Flexo central drum printing press 6 colors

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Machine Code FL927
Manufacturer UTECO
Model TOPAZ 608
Year 2010
Number of colors 6
Print possibilities 6 + 0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1350
Print width (mm) 1300
Min print repeat (mm) 390
Max print repeat (mm) 850
Unwinder type Turret SemiAutomatic Drop Splice
Max reel diameter unwinder (mm) 1000
Rewinder type Turret Aiutomatic
Max reel diameter rewinder (mm) 1000
Drying 2 zones , 4 fans , 4 mt drying tunnel , 2 gas burners
Videocamera Yes BST
Web guides Yes in and out
Vyscosity control No
Washing system Yes included
Inking system Closed chamber doctor blades
Anilox 1 set totally 6 ceramic anilox sleeves
Additional information Materials Paper up to 240 gsm
