BIELLONI MAGIFLEX flexographic printing machine 8 colors // Flexo CI // Printing machines // Used Flexo Press // Tecno Converting 2000 S.r.l.

** SOLD **

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Photo Gallery Video

Ask more informations

about a similar one

Machine Code: FL865
Manufacturer: BIELLONI
Modello: MAGIFLEX
Year: 2006
Number of colors: 8
Print possibilityes: 8+0
Gearless: Yes
Fast sleeve change: Yes
4 motor per deck CNC position system: Yes
Computer supervision: Yes
Web width (mm): 1320
Print width (mm): 1200
Min print repeat (mm): 300
Max print repeat (mm): 800
Unwinder type: Double brakdet
Max reel diameter unwinder (mm): 800
Rewinder type: Turret
Max reel diameter rewinder (mm): 800
Drying: Electric
Videocamera: Eltromat
Web guides: FIFE web tension control
Inking system: Closed chamber Doctor blades
Anilox: Yes
Print Sleeves: Yes

Machine Code	FL865
Manufacturer	BIELLONI
Modello	MAGIFLEX
Year	2006
Number of colors	8
Print possibilityes	8+0
Gearless	Yes
Fast sleeve change	Yes
4 motor per deck CNC position system	Yes
Computer supervision	Yes
Web width (mm)	1320
Print width (mm)	1200
Min print repeat (mm)	300
Max print repeat (mm)	800
Unwinder type	Double brakdet
Max reel diameter unwinder (mm)	800
Rewinder type	Turret
Max reel diameter rewinder (mm)	800
Drying	Electric
Videocamera	Eltromat
Web guides	FIFE web tension control
Inking system	Closed chamber Doctor blades
Anilox	Yes
Print Sleeves	Yes
