** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL924
- Manufacturer
- COMEXI
- Modello
- FB
- Year
- 2005
- Number of colors
- 8
- Overhaul/renovation
- Absolute carbon fibre closed chamber doctor blades system new 2019, Machine bearings replaced new 2018, Unwind and rewind splicing and chucks replaced new 2017, Air shafts 76mm new 2018 and old shafts refurbished, Ink system pumps and piping new 2018, Air conditioning replaced in Eltainer 2018.
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 850
- Unwinder type
- Turret
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones (print unit and drying tunnel), 2 gas burners, 4 fans
- Videocamera
- BST Permius, 3 chip camera, installed in 2012
- Corona treatment
- Vetaphone
- Vyscosity control
- Iinkspec, installed in 2016
- Washing system
- Auto washing system refurbished pneumatic control piping 2018
- Inking system
- Carbon fible doctor blades
- Anilox
- 14
- Print Sleeves
- 400mmx8, 410mmx16, 420mmx8, 425mmx 16, 440mmx 16, 455mmx8, 465mmx16, 485mmx16, 500mmx24, 515mmx8, 520mmx8, 530mmx6, 540mmx16, 570mmx8, 600mmx8, 610mmx8, 630mmx8, 645mmx8, 685mmx8, 710mmx8, 730mmx8, 750mmx8, 770mmx16
- Note
- Machine is fitted with a register system to print reverse in register with front
| Machine Code | FL924 |
| Manufacturer | COMEXI |
| Modello | FB |
| Year | 2005 |
| Number of colors | 8 |
| Overhaul/renovation | Absolute carbon fibre closed chamber doctor blades system new 2019, Machine bearings replaced new 2018, Unwind and rewind splicing and chucks replaced new 2017, Air shafts 76mm new 2018 and old shafts refurbished, Ink system pumps and piping new 2018, Air conditioning replaced in Eltainer 2018. |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1270 |
| Print width (mm) | 1220 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 850 |
| Unwinder type | Turret |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones (print unit and drying tunnel), 2 gas burners, 4 fans |
| Videocamera | BST Permius, 3 chip camera, installed in 2012 |
| Corona treatment | Vetaphone |
| Vyscosity control | Iinkspec, installed in 2016 |
| Washing system | Auto washing system refurbished pneumatic control piping 2018 |
| Inking system | Carbon fible doctor blades |
| Anilox | 14 |
| Print Sleeves | 400mmx8, 410mmx16, 420mmx8, 425mmx 16, 440mmx 16, 455mmx8, 465mmx16, 485mmx16, 500mmx24, 515mmx8, 520mmx8, 530mmx6, 540mmx16, 570mmx8, 600mmx8, 610mmx8, 630mmx8, 645mmx8, 685mmx8, 710mmx8, 730mmx8, 750mmx8, 770mmx16 |
| Note | Machine is fitted with a register system to print reverse in register with front |
