** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL921
- Manufacturer
- SCHIAVI
- Modello
- ALPHA
- Year
- 2001
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 325
- Max print repeat (mm)
- 650
- Unwinder type
- TURRET
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- TURRET
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones, 4 fans and 2 thermal oil heat exchangers. 1 zone inter colors 8.500m3/h, second zone is drying tunnel 10.300 m3/h: 2 x 18 nozels, tot 4,5 m length, Infrared lamps
- Videocamera
- BST
- Corona treatment
- yes
- Web guides
- 2 in and out
- Vyscosity control
- New celio
- Inking system
- Closed chamber doctor blades
- Print Sleeves
- approx 310 sleeves + approx 24 bridge sleeves/adapters
- Note
- CI drum diam 1800mm Hastelly surface Materials: Film from 10 my, Alu foil from 7 my, paper and laminates up to 120 gsm Plate thickness 1,14mm + 0,55mm Thermo regulation for CI drum LEL contol system Zellweger speed 350 m/min
Machine Code | FL921 |
Manufacturer | SCHIAVI |
Modello | ALPHA |
Year | 2001 |
Number of colors | 8 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1250 |
Print width (mm) | 1200 |
Min print repeat (mm) | 325 |
Max print repeat (mm) | 650 |
Unwinder type | TURRET |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | TURRET |
Max reel diameter rewinder (mm) | 1000 |
Drying | 2 zones, 4 fans and 2 thermal oil heat exchangers. 1 zone inter colors 8.500m3/h, second zone is drying tunnel 10.300 m3/h: 2 x 18 nozels, tot 4,5 m length, Infrared lamps |
Videocamera | BST |
Corona treatment | yes |
Web guides | 2 in and out |
Vyscosity control | New celio |
Inking system | Closed chamber doctor blades |
Print Sleeves | approx 310 sleeves + approx 24 bridge sleeves/adapters |
Note | CI drum diam 1800mm Hastelly surface Materials: Film from 10 my, Alu foil from 7 my, paper and laminates up to 120 gsm Plate thickness 1,14mm + 0,55mm Thermo regulation for CI drum LEL contol system Zellweger speed 350 m/min |
