UTECO EMERALD 107 Flexo printer 10 colors ** SOLD ** Ask more informations about a similar one

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Machine Code FL803
Manufacturer UTECO
Model EMERALD 107
Year 2003
Number of colors 10
Print possibilities 10+Solventless lamination
Overhaul/renovation Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017.
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1250
Print width (mm) 1200
Min print repeat (mm) 350
Max print repeat (mm) 800
Unwinder type Turret automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 800
Drying 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll
Videocamera yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection
Corona treatment yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated
Web guides yes
Vyscosity control yes new Gama 2017
Washing system yes
Inking system doctor blades - new 2016
Anilox 40 ceramic anilox sleeves
Print Sleeves 800 totally
Additional information 10 color CI with solventless lamination in line

** SOLD **
