** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- FL803
- Manufacturer
- UTECO
- Modello
- EMERALD 107
- Year
- 2003
- Number of colors
- 10
- Print possibilityes
- 10+Solventless lamination
- Overhaul/renovation
- Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017.
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll
- Videocamera
- yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection
- Corona treatment
- yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated
- Web guides
- yes
- Vyscosity control
- yes new Gama 2017
- Washing system
- yes
- Inking system
- doctor blades - new 2016
- Anilox
- 40 ceramic anilox sleeves
- Print Sleeves
- 800 totally
- Note
- 10 color CI with solventless lamination in line
Machine Code | FL803 |
Manufacturer | UTECO |
Modello | EMERALD 107 |
Year | 2003 |
Number of colors | 10 |
Print possibilityes | 10+Solventless lamination |
Overhaul/renovation | Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017. |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1250 |
Print width (mm) | 1200 |
Min print repeat (mm) | 350 |
Max print repeat (mm) | 800 |
Unwinder type | Turret automatic |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret automatic |
Max reel diameter rewinder (mm) | 800 |
Drying | 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll |
Videocamera | yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection |
Corona treatment | yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated |
Web guides | yes |
Vyscosity control | yes new Gama 2017 |
Washing system | yes |
Inking system | doctor blades - new 2016 |
Anilox | 40 ceramic anilox sleeves |
Print Sleeves | 800 totally |
Note | 10 color CI with solventless lamination in line |
