UTECO EMERALD 825 GL 8+1 Flexo central drum printing press 9 colors ** SOLD ** Ask more informations about a similar one

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Machine Code FL796
Manufacturer UTECO
Model EMERALD 825 GL 8+1
Year 2001
Number of colors 9
Print possibilities 8 (front) flexo + 1 (front) roto ; 1 (front) flexo + 1(back) roto
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1250
Print width (mm) 1200
Min print repeat (mm) 330
Max print repeat (mm) 700
Unwinder type Turret semi automatic
Max reel diameter unwinder (mm) 800
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 800
Drying Thermal oil
Videocamera No
Corona treatment Vetapone
Web guides FIFE
Vyscosity control No
Washing system No
Inking system 8 doctor blades ; 8 ink pumps
Anilox 1x4.5\400 ;3x5.5\340,6x5.5\300,1x4.7\315,1x4.4\400,1x7\280,1x5\280,1x5\290 ,1x7.5\160,1x8.5\110,1x7\160,2x12\160,3x12\120,1x10\140, 1x10\80 ,1x12\80, 1x20\80
Print Sleeves 8x350,8x360,8x370,8x374,8x380,8x390,13x400,8x410,8x415,8x420,13x430 ,8x440,18x450,7x460,8x465,8x470,13x480,8x490,9x510,8x520,7x521,8x525, 8x530,11x540,8v550,8x566,8x570,8x582,8x590,8x610,8x630,8x650,8x660
Additional information Number of colors:8 flexo + 1 gravure. Thickness of printing plates and of adhesive for the plate:1.14 + 0.55 Control tension type:Dancer Speed 300m/min Materials: Bopp/OPP/PP 15-50my; PET 15-25my; LDPE 40-150my;paper 30-120 gr/m2; Alu foil 29-40my Thermostat for CI 19m lenght - 5.23 Height Installed power 220 kw Preregister Length register controlled by PLC Pre- register system Refrigerating unit for cooling cylinder Driven Infeed calender with tension control

** SOLD **
