FLEXOTECNICA TACHYS Flexo printer 8 colors

** SOLD **

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Ask more informations
about a similar one
Machine Code
FL790
Manufacturer
FLEXOTECNICA
Model
TACHYS
Year
1998
Number of colors
8
Gearless
No
Fast sleeve change
Yes
4 motor per deck CNC position system
No
Computer supervision
Yes
Web width (mm)
1050
Print width (mm)
1000
Min print repeat (mm)
300
Max print repeat (mm)
650
Unwinder type
Flying splice
Max reel diameter unwinder (mm)
800
Rewinder type
Flying splice
Max reel diameter rewinder (mm)
800
Drying
Gas
Videocamera
Yes
Web guides
Yes
Washing system
No
Inking system
Solvent based. Chamber Doctor Blade
Anilox
20 as follows: 2x140L ;3x160L ;1x240L;4x400L; 1x14Vx100L ; 1x12Vx180L ; 2x10Vx200L;1x6Vx260L;1x8Vx280L;2x5,4Vx320L;2x490Vx320L
Print Sleeves
237 as follows: 11x300;8x310330,340,400,460,480,520,560,640 ; 7x320; 10x350,; 9x360, 22x380,4x390,13x410; 12x420; 16x430,450,; 24x440; 15x500m-m
Additional information
Speed: 250m/min Pre register automatic Computer system type Fast one
Machine Code FL790
Manufacturer FLEXOTECNICA
Model TACHYS
Year 1998
Number of colors 8
Gearless No
Fast sleeve change Yes
4 motor per deck CNC position system No
Computer supervision Yes
Web width (mm) 1050
Print width (mm) 1000
Min print repeat (mm) 300
Max print repeat (mm) 650
Unwinder type Flying splice
Max reel diameter unwinder (mm) 800
Rewinder type Flying splice
Max reel diameter rewinder (mm) 800
Drying Gas
Videocamera Yes
Web guides Yes
Washing system No
Inking system Solvent based. Chamber Doctor Blade
Anilox 20 as follows: 2x140L ;3x160L ;1x240L;4x400L; 1x14Vx100L ; 1x12Vx180L ; 2x10Vx200L;1x6Vx260L;1x8Vx280L;2x5,4Vx320L;2x490Vx320L
Print Sleeves 237 as follows: 11x300;8x310330,340,400,460,480,520,560,640 ; 7x320; 10x350,; 9x360, 22x380,4x390,13x410; 12x420; 16x430,450,; 24x440; 15x500m-m
Additional information Speed: 250m/min Pre register automatic Computer system type Fast one
