SCHIAVI POLARIS 136 flexo printing machine 6 colors

** SOLD **

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Ask more informations
about a similar one
Machine Code
FL771
Manufacturer
SCHIAVI
Model
POLARIS 136
Year
1997
Number of colors
6
Gearless
No
Fast sleeve change
No
Computer supervision
Yes
Web width (mm)
920
Print width (mm)
870
Min print repeat (mm)
300
Max print repeat (mm)
800
Unwinder type
Double spindle turret drop splice
Max reel diameter unwinder (mm)
800
Rewinder type
Double spindle turret flying splice
Max reel diameter rewinder (mm)
800
Drying
Gas burner.Drying system:Hot air
Inking system
solvent based.Enclosed doctor blade chambers with ceramic anilox rollers.6 ink pumps.
Anilox
anilox rollers ceramic coated and laser engraved, as following: 1 roller engraved with screen 280 lines/inch, volumes 5;3 rollers engraved with screen 280 lines/inch, volumes 12;2 rollers engraved with screen 300 lines/inch, volumes 14;2 rollers engraved with screen 350 lines/inch, volumes 9;2 rollers engraved with screen 450 lines/inch, volumes 7;2 rollers engraved with screen 550 lines/inch, volumes 5.
Additional information
Substrates able to process :Plastic films Speed: 250 m./min. Bull-gear, pitch 10 mm. Lenght registers : motorized remote controlled. Side registers: manual. Decks’ positioning system :motorized. Locking system of the printing units: manual. Video inspection system
Machine Code FL771
Manufacturer SCHIAVI
Model POLARIS 136
Year 1997
Number of colors 6
Gearless No
Fast sleeve change No
Computer supervision Yes
Web width (mm) 920
Print width (mm) 870
Min print repeat (mm) 300
Max print repeat (mm) 800
Unwinder type Double spindle turret drop splice
Max reel diameter unwinder (mm) 800
Rewinder type Double spindle turret flying splice
Max reel diameter rewinder (mm) 800
Drying Gas burner.Drying system:Hot air
Inking system solvent based.Enclosed doctor blade chambers with ceramic anilox rollers.6 ink pumps.
Anilox anilox rollers ceramic coated and laser engraved, as following: 1 roller engraved with screen 280 lines/inch, volumes 5;3 rollers engraved with screen 280 lines/inch, volumes 12;2 rollers engraved with screen 300 lines/inch, volumes 14;2 rollers engraved with screen 350 lines/inch, volumes 9;2 rollers engraved with screen 450 lines/inch, volumes 7;2 rollers engraved with screen 550 lines/inch, volumes 5.
Additional information Substrates able to process :Plastic films Speed: 250 m./min. Bull-gear, pitch 10 mm. Lenght registers : motorized remote controlled. Side registers: manual. Decks’ positioning system :motorized. Locking system of the printing units: manual. Video inspection system
** SOLD **
