** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- FL738
- Manufacturer
- UTECO
- Modello
- ONYX 808
- Year
- 2007
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 850
- Unwinder type
- Turret Automatic flying splice - roll loading system
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic flying splice - roll loading system
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones - 4 fans- 4 mt tunnel - 2 thermo il heaters - automtic recircultion system with LEL control system
- Videocamera
- yes
- Corona treatment
- No
- Web guides
- yes
- Vyscosity control
- yes
- Washing system
- yes
- Inking system
- Close dchamber doctor blades
- Anilox
- 12 ceramic anilox sleeves
- Print Sleeves
- 15 sets of print sleeves
| Machine Code | FL738 |
| Manufacturer | UTECO |
| Modello | ONYX 808 |
| Year | 2007 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1250 |
| Print width (mm) | 1200 |
| Min print repeat (mm) | 380 |
| Max print repeat (mm) | 850 |
| Unwinder type | Turret Automatic flying splice - roll loading system |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret Automatic flying splice - roll loading system |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones - 4 fans- 4 mt tunnel - 2 thermo il heaters - automtic recircultion system with LEL control system |
| Videocamera | yes |
| Corona treatment | No |
| Web guides | yes |
| Vyscosity control | yes |
| Washing system | yes |
| Inking system | Close dchamber doctor blades |
| Anilox | 12 ceramic anilox sleeves |
| Print Sleeves | 15 sets of print sleeves |
