** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL666
- Manufacturer
- FLEXOTECNICA
- Modello
- CHRONOS
- Year
- 2007
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1320
- Print width (mm)
- 1270
- Min print repeat (mm)
- 370
- Max print repeat (mm)
- 800
- Unwinder type
- Flying splice turret for reels 1000 mm diameter
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Flying splice turret for reels 1000 mm diameter
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Heated Air 2 zones gas burners
- Videocamera
- video inspection system AVT-Jupiter/Dual mode with pREgister automatic register pre-setting
- Web guides
- YES
- Vyscosity control
- YES
- Washing system
- Automatic wash-up system for 8 print units.
- Inking system
- Ink pumping
- Anilox
- Anilox sleeves ceramic coated and laser engraved. Specifications to be discussed among those on stock by the seller.
- Print Sleeves
- Print sleeves as following: 16 sleeves for print repeats 375 mm.; 8 sleeves for print repeats 400 mm.; 8 sleeves for print repeats 410 mm.; 8 sleeves for print repeats 425 mm.; 8 sleeves for print repeats 445 mm.; 8 sleeves for print repeats 470 mm.; 8 sleeves for print repeats 480 mm.; 16 sleeves for print repeats 490 mm
- Note
- 8 carbon fibre plate roller air mandrels diameter 108,342 mm. for the print section; 8 bridge sleeves external diameter 152,905 mm. for the print section Motorized registers
Machine Code | FL666 |
Manufacturer | FLEXOTECNICA |
Modello | CHRONOS |
Year | 2007 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1320 |
Print width (mm) | 1270 |
Min print repeat (mm) | 370 |
Max print repeat (mm) | 800 |
Unwinder type | Flying splice turret for reels 1000 mm diameter |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Flying splice turret for reels 1000 mm diameter |
Max reel diameter rewinder (mm) | 1000 |
Drying | Heated Air 2 zones gas burners |
Videocamera | video inspection system AVT-Jupiter/Dual mode with pREgister automatic register pre-setting |
Web guides | YES |
Vyscosity control | YES |
Washing system | Automatic wash-up system for 8 print units. |
Inking system | Ink pumping |
Anilox | Anilox sleeves ceramic coated and laser engraved. Specifications to be discussed among those on stock by the seller. |
Print Sleeves | Print sleeves as following: 16 sleeves for print repeats 375 mm.; 8 sleeves for print repeats 400 mm.; 8 sleeves for print repeats 410 mm.; 8 sleeves for print repeats 425 mm.; 8 sleeves for print repeats 445 mm.; 8 sleeves for print repeats 470 mm.; 8 sleeves for print repeats 480 mm.; 16 sleeves for print repeats 490 mm |
Note | 8 carbon fibre plate roller air mandrels diameter 108,342 mm. for the print section; 8 bridge sleeves external diameter 152,905 mm. for the print section Motorized registers |
