** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL643
- Manufacturer
- FISCHER & KRECKE
- Modello
- 34 DF
- Year
- 1999
- Number of colors
- 9
- Print possibilityes
- 8 colors flexo + 1 rotogravure. 9 col printing or 8 col printing and 1 for cold/hot seal or laquers.
- Gearless
- No
- Fast sleeve change
- No
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1280
- Print width (mm)
- 1250
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 1030
- Unwinder type
- Turret
- Max reel diameter unwinder (mm)
- 1250
- Rewinder type
- Turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 4 Gas burners 4 fans. Flexo unit drying: 2 zones one for inter- color flexo on CI and second is a 5m long drying tunnel. Rotogravure drying: 2 drying hood 6m length eachwith independent ventilations and heaters. tot 12 m.
- Videocamera
- 2 x Eltromat High resolution camera. for fron side and back side
- Web guides
- BST web control
- Inking system
- Chamber doctor blades. 7 chamber in carbon fibers and 5 in alluminium. Ink tanks.Electric Ink pumps. motor under inverter
- Anilox
- 16 anilox roller: 2x 400 l/cm -60°-5,2 cm³/m² ; 3x 380 i/cm -60°-3,8/4,9cm³/m² ; 6x 340 l/cm -60°-5,5cm³/m² ; 6x 300 l/cm –60°-4,3-7,7cm³/m² ; 2x 255 l/cm –60°-6,0 -9 cm³/m² ; 2x 240 l/cm –60°-7,9 -9,3 cm³/m² ; 4x 220 l/cm –60°-8,2 cm³/m² ; 6x 180 l/cm –60°-7,2 cm³/m² ; 2x 160 l/cm –60°-10 cm³/m² ; 2x 150 l/cm –60°-9,4cm³/m² ; 2x 140 l/cm –60°-7,3 cm³/m² ; 2x 120 l/cm –60°-7,7cm³/m²
- Print Sleeves
- No. Several gears and air mandrels available
- Print cylinders
- 127,388x 8:420 ;136,942x2: 450 ; 143,312x8:470 ; 152,866x8:500 ; 162,420x16:530 ; 168,789x16:550 ; 175,159x8:570 ; 191,082x8:620 ; 210,191x8:680 ; 219,745x8: 710 ; 229.229x8:740 ; 245,215x8:790
- Note
- •V= max.365m/min •temperature control unit and cold water composition •Gravure unit for front or reverse side (turn-cross in the ground) UNWINDING: •possibility to unwind front or reverse side to be preferred printing side •winding shafts 2x 76mm and 2x 150mm •automatic reel change REWINDING: •Possibility to rewind front or reverse side to be preferred reel outside •winding shafts 2 x 76mm und 2 x 150mm DIMENSIONS: •Width: 11m •Length: 30m •Height: 6m •Diameter central cylinder 2,26 mm = 7,1 m circumference
| Machine Code | FL643 |
| Manufacturer | FISCHER & KRECKE |
| Modello | 34 DF |
| Year | 1999 |
| Number of colors | 9 |
| Print possibilityes | 8 colors flexo + 1 rotogravure. 9 col printing or 8 col printing and 1 for cold/hot seal or laquers. |
| Gearless | No |
| Fast sleeve change | No |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1280 |
| Print width (mm) | 1250 |
| Min print repeat (mm) | 380 |
| Max print repeat (mm) | 1030 |
| Unwinder type | Turret |
| Max reel diameter unwinder (mm) | 1250 |
| Rewinder type | Turret |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 4 Gas burners 4 fans. Flexo unit drying: 2 zones one for inter- color flexo on CI and second is a 5m long drying tunnel. Rotogravure drying: 2 drying hood 6m length eachwith independent ventilations and heaters. tot 12 m. |
| Videocamera | 2 x Eltromat High resolution camera. for fron side and back side |
| Web guides | BST web control |
| Inking system | Chamber doctor blades. 7 chamber in carbon fibers and 5 in alluminium. Ink tanks.Electric Ink pumps. motor under inverter |
| Anilox | 16 anilox roller: 2x 400 l/cm -60°-5,2 cm³/m² ; 3x 380 i/cm -60°-3,8/4,9cm³/m² ; 6x 340 l/cm -60°-5,5cm³/m² ; 6x 300 l/cm –60°-4,3-7,7cm³/m² ; 2x 255 l/cm –60°-6,0 -9 cm³/m² ; 2x 240 l/cm –60°-7,9 -9,3 cm³/m² ; 4x 220 l/cm –60°-8,2 cm³/m² ; 6x 180 l/cm –60°-7,2 cm³/m² ; 2x 160 l/cm –60°-10 cm³/m² ; 2x 150 l/cm –60°-9,4cm³/m² ; 2x 140 l/cm –60°-7,3 cm³/m² ; 2x 120 l/cm –60°-7,7cm³/m² |
| Print Sleeves | No. Several gears and air mandrels available |
| Print cylinders | 127,388x 8:420 ;136,942x2: 450 ; 143,312x8:470 ; 152,866x8:500 ; 162,420x16:530 ; 168,789x16:550 ; 175,159x8:570 ; 191,082x8:620 ; 210,191x8:680 ; 219,745x8: 710 ; 229.229x8:740 ; 245,215x8:790 |
| Note | •V= max.365m/min •temperature control unit and cold water composition •Gravure unit for front or reverse side (turn-cross in the ground) UNWINDING: •possibility to unwind front or reverse side to be preferred printing side •winding shafts 2x 76mm and 2x 150mm •automatic reel change REWINDING: •Possibility to rewind front or reverse side to be preferred reel outside •winding shafts 2 x 76mm und 2 x 150mm DIMENSIONS: •Width: 11m •Length: 30m •Height: 6m •Diameter central cylinder 2,26 mm = 7,1 m circumference |
