** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL640
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- STELLAFLEX
- Year
- 1996
- Number of colors
- 8
- Gearless
- No
- Fast sleeve change
- No
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1320
- Print width (mm)
- 1270
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 1070
- Unwinder type
- Turret
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Diathermic oil
- Videocamera
- No
- Web guides
- 2 edge guides BST
- Vyscosity control
- Yes
- Inking system
- Doctor blae chamber. 8 ink pumps
- Anilox
- 26 as follows 5x 80L/cm ; 4x120L/cm; 2x140L/cm;3x160L/cm;5x225L/cm;7x320L/cm
- Print Sleeves
- Sleeves cliche 2,84 mm as follows: 5x330,350,380,16x440;8x470;8x480;8x520;8x560;9x530;5x570;8x600;4x900;8x1000;16x1110;6x1170mm ; Sleeves cliche 1,14 as follows: 11x350mm,8x380,16x400,16x420mm;8x440;16x460;8+8x480;16x500;8x510;7x520;8x570;17x590;16x600;8x660;7x1050;15x1070mm
- Note
- Mechanical speed 300m/min. Gear pitch 10mm Material: plastic film 12-200my Cliche thickness 1,14/2,84 4 airshafts 3" Hot water heating type Inline slitting with 1 knive Portalift system for automatic cylinder's loading. 48 gears cylinders Spare parts : 2 doctor blade chamber; 4 color trays; 3 color pot Dimensions of printer 19,5mx7m Air mandrels: 8x300,9x370,8x420,7x440,9x460,9x500,5x530;2x570;6x660;6x650;16x950mm
| Machine Code | FL640 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Modello | STELLAFLEX |
| Year | 1996 |
| Number of colors | 8 |
| Gearless | No |
| Fast sleeve change | No |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1320 |
| Print width (mm) | 1270 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 1070 |
| Unwinder type | Turret |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | Diathermic oil |
| Videocamera | No |
| Web guides | 2 edge guides BST |
| Vyscosity control | Yes |
| Inking system | Doctor blae chamber. 8 ink pumps |
| Anilox | 26 as follows 5x 80L/cm ; 4x120L/cm; 2x140L/cm;3x160L/cm;5x225L/cm;7x320L/cm |
| Print Sleeves | Sleeves cliche 2,84 mm as follows: 5x330,350,380,16x440;8x470;8x480;8x520;8x560;9x530;5x570;8x600;4x900;8x1000;16x1110;6x1170mm ; Sleeves cliche 1,14 as follows: 11x350mm,8x380,16x400,16x420mm;8x440;16x460;8+8x480;16x500;8x510;7x520;8x570;17x590;16x600;8x660;7x1050;15x1070mm |
| Note | Mechanical speed 300m/min. Gear pitch 10mm Material: plastic film 12-200my Cliche thickness 1,14/2,84 4 airshafts 3" Hot water heating type Inline slitting with 1 knive Portalift system for automatic cylinder's loading. 48 gears cylinders Spare parts : 2 doctor blade chamber; 4 color trays; 3 color pot Dimensions of printer 19,5mx7m Air mandrels: 8x300,9x370,8x420,7x440,9x460,9x500,5x530;2x570;6x660;6x650;16x950mm |
