- Code Machine
- LA503
- Fabricant
- NORDMECCANICA
- Modello
- Super Combi 3000
- Année
- 2010
- Application
- Duplex lamination
- Type of lamination/coating
- COMBI / INTECHANGEABLE TROLLEY
- Working width (mm)
- 1300
- First unwinder type
- Shaftless driven
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- Shaftless driven
- Max diameter reel unwinder
- 1000
- Rewinder type
- Shaftless driven
- Max diameter reel rewinder
- 1000
- Coating unit
- available with 1x solvent less trolley 5 rollers staggered and 2x Gravure trolley for water and solvent based coating /lamination
- Drying
- 4 fans, 2 zones, 2 hoods. 2x electric heaters
- pumping mixing unit
- Worldmixer 2 components for solvent less glue
- Corona treatment
- 2 x AFS corona treaters
| Code Machine | LA503 |
| Fabricant | NORDMECCANICA |
| Modello | Super Combi 3000 |
| Année | 2010 |
| Application | Duplex lamination |
| Type of lamination/coating | COMBI / INTECHANGEABLE TROLLEY |
| Working width (mm) | 1300 |
| First unwinder type | Shaftless driven |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | Shaftless driven |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Shaftless driven |
| Max diameter reel rewinder | 1000 |
| Coating unit | available with 1x solvent less trolley 5 rollers staggered and 2x Gravure trolley for water and solvent based coating /lamination |
| Drying | 4 fans, 2 zones, 2 hoods. 2x electric heaters |
| pumping mixing unit | Worldmixer 2 components for solvent less glue |
| Corona treatment | 2 x AFS corona treaters |
