- Code Machine
- FL1217
- Fabricant
- UTECO
- Modello
- Crystal 108
- Année
- 2019
- Number of colors
- 10
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 850
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1000
- Videocamera
- Grafikontrol 100% defect control
- Corona treatment
- Ferrarini & Benelli
- Web guides
- BST
- Vyscosity control
- Gama G26
- Washing system
- Yes
- Inking system
- Closed Chamber doctor blades
- Note
- max. mechanical speed- 500m/min "Touch & Go" System "Tune & Go" System "kiss & Go" System "Click & Drag" System,
| Code Machine | FL1217 |
| Fabricant | UTECO |
| Modello | Crystal 108 |
| Année | 2019 |
| Number of colors | 10 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 850 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 1000 |
| Videocamera | Grafikontrol 100% defect control |
| Corona treatment | Ferrarini & Benelli |
| Web guides | BST |
| Vyscosity control | Gama G26 |
| Washing system | Yes |
| Inking system | Closed Chamber doctor blades |
| Note | max. mechanical speed- 500m/min "Touch & Go" System "Tune & Go" System "kiss & Go" System "Click & Drag" System, |
