- Code Machine
- FL896
- Fabricant
- FISCHER & KRECKE
- Modello
- FP15 S
- Année
- 2012
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones 4 fans 2 gas burners
- Videocamera
- yes
- Web guides
- Yes in and out
- Vyscosity control
- yes automatic by Selectra
- Washing system
- yes
- Inking system
- Closed chamber doctor blades
- Anilox
- 16 ceramic anilox sleeves : 5x 420 L/cm-vol.4,5 ; 1x 225 L/cm- vol.6 ; 1x 200 L/cm-vol.6 ; 3x 200 L/cm-vol.8; 1x 180 L/cm-vol.9; 2x 110 L/cm-vol.12 ; 2 x 80 L/cm-vol.15 ; 1x 60 L7cm.vol.18;
- Print Sleeves
- 256 print sleeves , 8 for each repeat as follwos: 370, 380, 390, 400,410, 420, 430 , 440 , 450, 460 , 470 , 480 , 490 , 500 , 510 , 520, 530 , 540, 550 , 560, 570, 580, 600 , 620 , 630, 640 , 660, 700, 720, 760
- Note
- AUTO REGISTER SYSTEM AND PRINT SET UP with GPS system
Code Machine | FL896 |
Fabricant | FISCHER & KRECKE |
Modello | FP15 S |
Année | 2012 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1270 |
Print width (mm) | 1220 |
Min print repeat (mm) | 380 |
Max print repeat (mm) | 800 |
Unwinder type | Turret Automatic |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret Automatic |
Max reel diameter rewinder (mm) | 1000 |
Drying | 2 zones 4 fans 2 gas burners |
Videocamera | yes |
Web guides | Yes in and out |
Vyscosity control | yes automatic by Selectra |
Washing system | yes |
Inking system | Closed chamber doctor blades |
Anilox | 16 ceramic anilox sleeves : 5x 420 L/cm-vol.4,5 ; 1x 225 L/cm- vol.6 ; 1x 200 L/cm-vol.6 ; 3x 200 L/cm-vol.8; 1x 180 L/cm-vol.9; 2x 110 L/cm-vol.12 ; 2 x 80 L/cm-vol.15 ; 1x 60 L7cm.vol.18; |
Print Sleeves | 256 print sleeves , 8 for each repeat as follwos: 370, 380, 390, 400,410, 420, 430 , 440 , 450, 460 , 470 , 480 , 490 , 500 , 510 , 520, 530 , 540, 550 , 560, 570, 580, 600 , 620 , 630, 640 , 660, 700, 720, 760 |
Note | AUTO REGISTER SYSTEM AND PRINT SET UP with GPS system |
