- Código Máquina
- EX838
- Constructor
- WINDMÖLLER & HÖLSCHER
- Modello
- Varex
- Año
- 2002
- Number of layers
- 3
- Film structure
- ABC
- Film Width
- 2200
- Output (Kg/h)
- 450 kg/h
- Extruder 1 Layer ref:
- A
- Screw diam 1
- 70mm
- Extruder 2 Layer ref:
- B
- Screw diam 2
- 90mm
- Extruder 3 Layer ref:
- C
- Screw diam 3
- 70mm
- Die diam (mm)
- 500mm, gap 2.4
- Corona treatment
- Yes, both side
- Rewinder max reel diameter
- 1000mm
- Note
- thickness range 15-250 inner air circulation profile control gel detection deionising cores 76/152 mm
| Código Máquina | EX838 |
| Constructor | WINDMÖLLER & HÖLSCHER |
| Modello | Varex |
| Año | 2002 |
| Number of layers | 3 |
| Film structure | ABC |
| Film Width | 2200 |
| Output (Kg/h) | 450 kg/h |
| Extruder 1 Layer ref: | A |
| Screw diam 1 | 70mm |
| Extruder 2 Layer ref: | B |
| Screw diam 2 | 90mm |
| Extruder 3 Layer ref: | C |
| Screw diam 3 | 70mm |
| Die diam (mm) | 500mm, gap 2.4 |
| Corona treatment | Yes, both side |
| Rewinder max reel diameter | 1000mm |
| Note | thickness range 15-250 inner air circulation profile control gel detection deionising cores 76/152 mm |
