- Código Máquina
- LA538
- Constructor
- ROTOMEC
- Modello
- ROTOPAK 3000-S/1200/400
- Año
- 2002
- Application
- Coating
- Type of lamination/coating
- SOLVENT / WATER BASED
- Working width (mm)
- 1220
- Speed
- 525mpm
- First unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Third unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Rewinder type
- Turret automatic
- Max diameter reel rewinder
- 1000
- Drying
- All 3 units are double hood, each with one supply fan and one exhaust fan.Drying Heat Source - Steam
- Note
- 3-station (2 reversible, 1 hotmelt) Drive: Independent Drive Machine HMI: Factory Talk, Windows 10 PLC: Siemens 6ES7414-2XJ01-0AB0, Profibus Drives: Siemens Dilution Control: Yes
| Código Máquina | LA538 |
| Constructor | ROTOMEC |
| Modello | ROTOPAK 3000-S/1200/400 |
| Año | 2002 |
| Application | Coating |
| Type of lamination/coating | SOLVENT / WATER BASED |
| Working width (mm) | 1220 |
| Speed | 525mpm |
| First unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Third unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Turret automatic |
| Max diameter reel rewinder | 1000 |
| Drying | All 3 units are double hood, each with one supply fan and one exhaust fan.Drying Heat Source - Steam |
| Note | 3-station (2 reversible, 1 hotmelt) Drive: Independent Drive Machine HMI: Factory Talk, Windows 10 PLC: Siemens 6ES7414-2XJ01-0AB0, Profibus Drives: Siemens Dilution Control: Yes |
NORDMECCANICA ZENIT
-
Código Máquina: LA250
-
Año: 1990
-
Working width (mm): 1300
REMAC Solventless with Microperforation
-
Código Máquina: LA447
-
Año: 2019
-
Working width (mm): 1400
Coatema
-
Código Máquina: LA469
-
Año: 2017
-
Working width (mm): 700
VALMET ROTOMEC
-
Código Máquina: LA516
-
Año: 1999
-
Working width (mm): 1400
UTECO Horizon D/TH
-
Código Máquina: LA481
-
Año: 2005
-
Working width (mm): 1320
NORDMECCANICA SIMPLEX COMBI
-
Código Máquina: LA495
-
Año: 1998
-
Working width (mm): 1315
