- Código Máquina
- ST158
- Constructor
- CMF
- Modello
- PAPERFLEX
- Año
- 1990
- Number of colors
- 6
- Print possibilityes
- 6+0, 5+1, 4+2, 3+3
- Tipo
- Reel to reel
- Web width (mm)
- 1450
- Print width (mm)
- 1400
- Print repeat (mm)
- 370-700 mm
- unwinder type
- single type
- Max diameter reel unwinder (mm)
- 1200
- Rewinder type
- single type
- Max diameter reel rewinder (mm)
- 1200
- Drying
- Machine could work with diferent systems; hot water, air and oil. From them, the one intalled currently is hot water.
- Anilox
- 2x70; 2x80, 1x100, 1x120,4x140 L/cm
- Print cylinders
- 10x370, 4x400, 8x450, 12x500, 6x540,8x560, 12x600, 6x650, 3x700 mm
- Note
- Printing speed: 200 m/min.Material: Paper 30-130 gr/m2.Rubber rollers as follows: 1x820, 1x910, 1x1090 mm (Dimensions :L = 13800 ,L = 4750 H = 4100 )
| Código Máquina | ST158 |
| Constructor | CMF |
| Modello | PAPERFLEX |
| Año | 1990 |
| Number of colors | 6 |
| Print possibilityes | 6+0, 5+1, 4+2, 3+3 |
| Tipo | Reel to reel |
| Web width (mm) | 1450 |
| Print width (mm) | 1400 |
| Print repeat (mm) | 370-700 mm |
| unwinder type | single type |
| Max diameter reel unwinder (mm) | 1200 |
| Rewinder type | single type |
| Max diameter reel rewinder (mm) | 1200 |
| Drying | Machine could work with diferent systems; hot water, air and oil. From them, the one intalled currently is hot water. |
| Anilox | 2x70; 2x80, 1x100, 1x120,4x140 L/cm |
| Print cylinders | 10x370, 4x400, 8x450, 12x500, 6x540,8x560, 12x600, 6x650, 3x700 mm |
| Note | Printing speed: 200 m/min.Material: Paper 30-130 gr/m2.Rubber rollers as follows: 1x820, 1x910, 1x1090 mm (Dimensions :L = 13800 ,L = 4750 H = 4100 ) |
