CERUTTI R931 Impresora huecograbado 10 colores

Código Máquina
RO144
Constructor
CERUTTI
Modello
R931
Año
2006
Number of colors
10
Drive
Cardan
Trolley system
Yes
Web width (mm)
1470
Print width (mm)
1420
Print repeat range (mm)
400-900 mm
Drying specifications
7 units (2-8 Single drying Hood 2,5mt - 1 blowing fan for each unit); 2 units(1 & 9 - with double hood 2x3mt and 2 blowing fans) ; 1 unit (10 - 2 extended hoods 2x3,6 mt with 2 blowing fans)
Drying heat surce
Thermo Oil
Unwinder type
Automatic Turret
Max reel diameter unwinder (mm)
1000
Rewinder type
Automatic Turret
Max reel diameter rewinder (mm)
1000
Videocamera
Yes
Register controll
Yes
Vyscosity control
Gamma VIS G25
Corona treatment
Yes, Double Side Mero
Note
Preconditioning Hood
Código Máquina RO144
Constructor CERUTTI
Modello R931
Año 2006
Number of colors 10
Drive Cardan
Trolley system Yes
Web width (mm) 1470
Print width (mm) 1420
Print repeat range (mm) 400-900 mm
Drying specifications 7 units (2-8 Single drying Hood 2,5mt - 1 blowing fan for each unit); 2 units(1 & 9 - with double hood 2x3mt and 2 blowing fans) ; 1 unit (10 - 2 extended hoods 2x3,6 mt with 2 blowing fans)
Drying heat surce Thermo Oil
Unwinder type Automatic Turret
Max reel diameter unwinder (mm) 1000
Rewinder type Automatic Turret
Max reel diameter rewinder (mm) 1000
Videocamera Yes
Register controll Yes
Vyscosity control Gamma VIS G25
Corona treatment Yes, Double Side Mero
Note Preconditioning Hood
