- Código Máquina
- FL674
- Constructor
- SCHIAVI
- Modello
- ALPHA
- Año
- 2001
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1120
- Print width (mm)
- 1070
- Min print repeat (mm)
- 320
- Max print repeat (mm)
- 650
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones, 4 fans, electric heaters , air recirculation system
- Videocamera
- BST
- Corona treatment
- Yes Ferrarini & Benelli GTS 8 T
- Web guides
- Yes in and out
- Inking system
- Closed chamber doctor blades
- Anilox
- ceramic sleeves
- Note
- Chiller Corema included
| Código Máquina | FL674 |
| Constructor | SCHIAVI |
| Modello | ALPHA |
| Año | 2001 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1120 |
| Print width (mm) | 1070 |
| Min print repeat (mm) | 320 |
| Max print repeat (mm) | 650 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones, 4 fans, electric heaters , air recirculation system |
| Videocamera | BST |
| Corona treatment | Yes Ferrarini & Benelli GTS 8 T |
| Web guides | Yes in and out |
| Inking system | Closed chamber doctor blades |
| Anilox | ceramic sleeves |
| Note | Chiller Corema included |
