- Código Máquina
- FL674
- Constructor
- SCHIAVI
- Modello
- ALPHA
- Año
- 2001
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1120
- Print width (mm)
- 1070
- Min print repeat (mm)
- 320
- Max print repeat (mm)
- 650
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones, 4 fans, electric heaters , air recirculation system
- Videocamera
- BST
- Corona treatment
- Yes Ferrarini & Benelli GTS 8 T
- Web guides
- Yes in and out
- Inking system
- Closed chamber doctor blades
- Anilox
- ceramic sleeves
- Note
- Chiller Corema included
Código Máquina | FL674 |
Constructor | SCHIAVI |
Modello | ALPHA |
Año | 2001 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1120 |
Print width (mm) | 1070 |
Min print repeat (mm) | 320 |
Max print repeat (mm) | 650 |
Unwinder type | Turret automatic |
Max reel diameter unwinder (mm) | 800 |
Rewinder type | Turret automatic |
Max reel diameter rewinder (mm) | 800 |
Drying | 2 zones, 4 fans, electric heaters , air recirculation system |
Videocamera | BST |
Corona treatment | Yes Ferrarini & Benelli GTS 8 T |
Web guides | Yes in and out |
Inking system | Closed chamber doctor blades |
Anilox | ceramic sleeves |
Note | Chiller Corema included |
