3 layers REIFENHAUSER blown film extruder
In a blown film extruder PE granulates (or other polymer) are melted in an extruder and pushed through a circular die extruding a tube of molten polymer. Tube is then inflated to multiples of its initial diameter and cooled to form a thin film. Bobble is later collapsed and re-winded.
| Machine Code | EX637 |
| Manufacturer | REIFENHAUSER |
| Year | 2002 |
| Number of layers | 3 |
| Overhaul/renovation | New Thickness control system KUNDIG and automatic air ring of year 2015, PLC and HMI upgrade year 2013 , new screw and cylinders 2013 |
| Film structure | A-B-C |
| Material | LDPE, LLDPE , MDPE |
| Film Width (mm) | 1800 |
| Output (Kg/h) | 350 Kg/h |
| Extruder 1 Layer ref: | A |
| Screw diam | 70 |
| Description | Gravimetric dosing unit DOTECO 3 comp |
| Extruder 2 Layer ref: | B |
| Screw diam | 80 |
| Description | Gravimetric dosing unit DOTECO 3 comp |
| Extruder 3 Layer ref: | C |
| Screw diam | 70 |
| Description | Gravimetric dosing unit DOTECO 3 comp |
| Head description | Automatic Die |
| Die diam (mm) | 350 mm |
| Thickness controll system | YES automatic INNO PLAST |
| Bubble cage | yes |
| Panel for gussets | no |
| Take off unit | Oscillating |
| Corona treatment | YES Ferrarini Benelli |
| Web guide | Yes |
| Rewinder max reel diameter | 1000 |
| Rewinder description | MACCHI BO PLUS |
