3 layers REIFENHAUSER Cast film extrusion line
Cast film extrusion lines are commonly used to extrude plastic films especially for flexible packaging industry. / In a cast film extruder PE, PP or PA granulates (or other polymers) are melted inro an extruder and pushed through a flat extrusion die (T die), extruding a sheet of molten polymer onto a cooled roller (chill roll).
Machine Code | CA147 |
Manufacturer | REIFENHAUSER |
Year | 1991 |
Number of layers | 3 |
Material | CPP,LLDPE,HDPE, STRETCH, CPE, ADHESIVE, EVA |
Film width (mm) | 2100 |
Output (Kg/h) | 550 kg/h |
Screw diam | 120 |
Screw diam | 90 |
Screw diam | 70 |
Chill roll unit | Edge pinning Rolltex |
Thickness controll system | Automatic thickness control system |
Corona treatment | Yes - Make AFS with silicon roller |
Rewinder max reel diameter (mm) | 2500 |
Additional information | Thickness: 20-150 micron Inline edge trim recovery Including accessories: scrap recycling unit FS090.1-1-90-3.5; chiller; 320 kW/hour |
