** SOLD **
Rotogravure printing machines (roto or gravure for short) perform a type of intaglio printing process, which involves engraving the image onto a cylinder which become the image carrier. Every printing job will require its dedicated set of engraved cylinders.
Ask more informations
about a similar one
- Machine Code
- RO144
- Manufacturer
- CERUTTI
- Modello
- R931
- Year
- 2006
- Number of colors
- 10
- Drive
- Cardan
- Trolley system
- Yes
- Web width (mm)
- 1470
- Print width (mm)
- 1420
- Print repeat range (mm)
- 400-900 mm
- Drying specifications
- 7 units (2-8 Single drying Hood 2,5mt - 1 blowing fan for each unit); 2 units(1 & 9 - with double hood 2x3mt and 2 blowing fans) ; 1 unit (10 - 2 extended hoods 2x3,6 mt with 2 blowing fans)
- Drying heat surce
- Thermo Oil
- Unwinder type
- Automatic Turret
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Automatic Turret
- Max reel diameter rewinder (mm)
- 1000
- Videocamera
- Yes
- Register controll
- Yes
- Vyscosity control
- Gamma VIS G25
- Corona treatment
- Yes, Double Side Mero
- Note
- Preconditioning Hood
| Machine Code | RO144 |
| Manufacturer | CERUTTI |
| Modello | R931 |
| Year | 2006 |
| Number of colors | 10 |
| Drive | Cardan |
| Trolley system | Yes |
| Web width (mm) | 1470 |
| Print width (mm) | 1420 |
| Print repeat range (mm) | 400-900 mm |
| Drying specifications | 7 units (2-8 Single drying Hood 2,5mt - 1 blowing fan for each unit); 2 units(1 & 9 - with double hood 2x3mt and 2 blowing fans) ; 1 unit (10 - 2 extended hoods 2x3,6 mt with 2 blowing fans) |
| Drying heat surce | Thermo Oil |
| Unwinder type | Automatic Turret |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Automatic Turret |
| Max reel diameter rewinder (mm) | 1000 |
| Videocamera | Yes |
| Register controll | Yes |
| Vyscosity control | Gamma VIS G25 |
| Corona treatment | Yes, Double Side Mero |
| Note | Preconditioning Hood |
