OFEM COLUMBUS 7/906 flexo press 6 colors // Flexo CI // Printing machines // Used Flexo Press // Tecno Converting 2000 S.r.l.

** SOLD **

Flexo CI presses use a central drum which is common to all colours as counter impression roll.

Photo Gallery

Ask more informations

about a similar one

Machine Code: FL647
Manufacturer: OFEM
Modello: COLUMBUS 7/906
Year: 2000
Number of colors: 6
Print possibilityes: 6+0
Gearless: No
Fast sleeve change: No
Web width (mm): 1270
Print width (mm): 1200
Min print repeat (mm): 300
Max print repeat (mm): 900
Unwinder type: DOUBLE AXIS DROP SLICE
Max reel diameter unwinder (mm): 800
Rewinder type: DOUBLE AXIS TURRET FLYING SLICE
Max reel diameter rewinder (mm): 800
Drying: HOT AIR
Videocamera: YES
Web guides: YES, 1 before print and 1 before rewind
Inking system: 4 Printing units (stations 2-3-4-5) equipped with enclosed doctor blade chambers with ceramic anilox rollers;2 Printing units (stations 1 and 6) equipped with fountain rubber roller (machine prepared for application of enclosed doctor blades as the other units)
Anilox: 5 anilox roller ceramic coated and laser engraved to 120 lines/cm; • 2 anilox roller mechanically engraved (for fountain roller system) to 100 lines/cm.
Print cylinders: complete with gears as follows:6 repeat length 320 mm.;6 repeat length 350 mm ;6 repeat length 370 mm ;6 repeat length 400 mm; 6 repeat length 430 mm;6 repeat length 460 mm ;6 repeat length 480 mm ;6 repeat length 500 mm.;6 repeat length 550 mm.;6 repeat length 600 mm.;6 repeat length 620 mm.;6 repeat length 650 mm.;6 repeat length 700 mm.;6 repeat length 750 mm.
Note: Material : plastic webs; Transmission type: bull-gear; Length registers: motorized remote controlled; Side registers: manual; Decks positioning system: automatic with microprocessor, 1 motor each deck; Locking system of the printing units: manual; Hoisting system: double electric hoists for printing rollers handling;

Machine Code	FL647
Manufacturer	OFEM
Modello	COLUMBUS 7/906
Year	2000
Number of colors	6
Print possibilityes	6+0
Gearless	No
Fast sleeve change	No
Web width (mm)	1270
Print width (mm)	1200
Min print repeat (mm)	300
Max print repeat (mm)	900
Unwinder type	DOUBLE AXIS DROP SLICE
Max reel diameter unwinder (mm)	800
Rewinder type	DOUBLE AXIS TURRET FLYING SLICE
Max reel diameter rewinder (mm)	800
Drying	HOT AIR
Videocamera	YES
Web guides	YES, 1 before print and 1 before rewind
Inking system	4 Printing units (stations 2-3-4-5) equipped with enclosed doctor blade chambers with ceramic anilox rollers;2 Printing units (stations 1 and 6) equipped with fountain rubber roller (machine prepared for application of enclosed doctor blades as the other units)
Anilox	5 anilox roller ceramic coated and laser engraved to 120 lines/cm; • 2 anilox roller mechanically engraved (for fountain roller system) to 100 lines/cm.
Print cylinders	complete with gears as follows:6 repeat length 320 mm.;6 repeat length 350 mm ;6 repeat length 370 mm ;6 repeat length 400 mm; 6 repeat length 430 mm;6 repeat length 460 mm ;6 repeat length 480 mm ;6 repeat length 500 mm.;6 repeat length 550 mm.;6 repeat length 600 mm.;6 repeat length 620 mm.;6 repeat length 650 mm.;6 repeat length 700 mm.;6 repeat length 750 mm.
Note	Material : plastic webs; Transmission type: bull-gear; Length registers: motorized remote controlled; Side registers: manual; Decks positioning system: automatic with microprocessor, 1 motor each deck; Locking system of the printing units: manual; Hoisting system: double electric hoists for printing rollers handling;
