Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.
Ask more informations
- Machine Code
- FL1213
- Manufacturer
- UTECO
- Modello
- ONYX - XS
- Year
- 2017
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 850
- Print width (mm)
- 820
- Min print repeat (mm)
- 260
- Max print repeat (mm)
- 650
- Unwinder type
- Automatic Turret - 3" shafts
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Automatic Turret - 3" shafts - Razor blade slitter
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones , 4 fans , 2 Gas burner , final tunnel 3,5 mt lenght, automatic air recirculation system with LEL control by MSA
- Videocamera
- Grafykontrol with automatic register (Click & drag) and defekt control
- Web guides
- yes in and out
- Vyscosity control
- Yes
- Washing system
- Yes
- Inking system
- Closed chamber doctor blades
- Anilox
- 18 ceramic anilox sleeves as follows : 4 x 480 Lines/m - vol 3,5 ; 4 x 420 L/cm-vol.4,5 ; 2x 340 L/cm-vol.5,5 ; 1x 300 L7cm- vol.4,5 ; 1x 280 L/cm.vol.8 ; 1x 240 L/cm-vol.10 ; 2x 200 L/cm-vol.9,5 ; 1x 180 L/cm- vol.9 ; 2x 160 L/cm- vol.12 ; 1x 140 L/cm- vol 14
- Print Sleeves
- 216 print sleeves as follows : 8 sleeves for each following repeat : 270 mm , 280 , 290 , 300 , 310 , 320 , 330 , 350 , 360 , 370 , 380 , 390 , 400 , 420 , 440 , 460 , 470 , 480 , 500 , 520 , 530 , 540 ,560 , 580 , 600 , 610 , 620 .
- Note
- Web cleaner ACE (HC20) Driven infeed calender 200 mm diam Automatic print setting system with "Kiss &Go" and "Tune & Go" Pre register "G" (guearless) Motorized length register Motorized lateral register (+/- 5 mm)
| Machine Code | FL1213 |
| Manufacturer | UTECO |
| Modello | ONYX - XS |
| Year | 2017 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 850 |
| Print width (mm) | 820 |
| Min print repeat (mm) | 260 |
| Max print repeat (mm) | 650 |
| Unwinder type | Automatic Turret - 3" shafts |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Automatic Turret - 3" shafts - Razor blade slitter |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones , 4 fans , 2 Gas burner , final tunnel 3,5 mt lenght, automatic air recirculation system with LEL control by MSA |
| Videocamera | Grafykontrol with automatic register (Click & drag) and defekt control |
| Web guides | yes in and out |
| Vyscosity control | Yes |
| Washing system | Yes |
| Inking system | Closed chamber doctor blades |
| Anilox | 18 ceramic anilox sleeves as follows : 4 x 480 Lines/m - vol 3,5 ; 4 x 420 L/cm-vol.4,5 ; 2x 340 L/cm-vol.5,5 ; 1x 300 L7cm- vol.4,5 ; 1x 280 L/cm.vol.8 ; 1x 240 L/cm-vol.10 ; 2x 200 L/cm-vol.9,5 ; 1x 180 L/cm- vol.9 ; 2x 160 L/cm- vol.12 ; 1x 140 L/cm- vol 14 |
| Print Sleeves | 216 print sleeves as follows : 8 sleeves for each following repeat : 270 mm , 280 , 290 , 300 , 310 , 320 , 330 , 350 , 360 , 370 , 380 , 390 , 400 , 420 , 440 , 460 , 470 , 480 , 500 , 520 , 530 , 540 ,560 , 580 , 600 , 610 , 620 . |
| Note | Web cleaner ACE (HC20) Driven infeed calender 200 mm diam Automatic print setting system with "Kiss &Go" and "Tune & Go" Pre register "G" (guearless) Motorized length register Motorized lateral register (+/- 5 mm) |
