Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
- Machine Code
- FL1207
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- Primaflex
- Year
- 2005
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 870
- Print width (mm)
- 820
- Min print repeat (mm)
- 250
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones, 4 fans , final tunnel, Gas burners
- Videocamera
- BST Premius
- Web guides
- 2 web guides
- Anilox
- 22 aniloxes : 1 x 120 linee cm/ 12, 8 cm³/m², 1 x 140 linee cm/ 13, 5 cm³/m², 1 x 160 linee cm/ 12, 3 cm³/m², 1 x 200 linee cm/ 9,5 cm³/m², 1 x 300 linee cm/ 7, 3 cm³/m², 1 x 360 linee cm/ 4, 8 cm³/m², 1 x 360 linee cm/ 5 cm³/m², 2 x 360 linee cm/ 4, 9 cm³/m², 3 x 400 linee cm/ 4, 5 cm³/m², 1 x 400 linee cm/ 4, 6 cm³/m², 1 x 160 linee cm/ 11 cm³/m², 1 x 200 linee cm/ 10 cm³/m², 1 x 280 linee cm/ 10 cm³/m², 1 x 360 linee cm/ 8 cm³/m², 1 x 460 linee cm/ 5 cm³/m², 1 x 580 linee cm/ 4 cm³/m², 1 x 140 linee cm/ 16,5 cm³/m², 1 x 140 linee cm/ 13,4 cm³/m², 1 x 200 linee cm/ 9,5 cm³/m²
- Print Sleeves
- 378 sleeves, 16 x 250mm, 16 x 260mm, 8 x 270mm, 8 x 280mm, 8 x 290mm, 8 x 300mm, 8 x 310mm, 8 x 320mm, 8 x 330mm, 8 x 340mm, 8 x 345mm, 16 x 350mm, 8 x 360mm, 8 x 375mm, 8 x 380mm, 16 x 390mm, 16 x 400mm, 8 x 410mm, 16 x 420mm, 16 x 430mm, 8 x 440mm, 8 x 450mm, 8 x 460mm, 8 x 470mm, 8 x 480mm, 8 x 490mm, 8 x 500mm, 8 x 520mm, 8 x 560mm, 8 x 580mm, 10 x 600mm, 8 x 610mm, 8 x 620mm, 8 x 640mm, 8 x 650mm, 8 x 680mm, 8 x 700mm, 8 x 730mm, 8 x 750mm
| Machine Code | FL1207 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Modello | Primaflex |
| Year | 2005 |
| Number of colors | 8 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 870 |
| Print width (mm) | 820 |
| Min print repeat (mm) | 250 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones, 4 fans , final tunnel, Gas burners |
| Videocamera | BST Premius |
| Web guides | 2 web guides |
| Anilox | 22 aniloxes : 1 x 120 linee cm/ 12, 8 cm³/m², 1 x 140 linee cm/ 13, 5 cm³/m², 1 x 160 linee cm/ 12, 3 cm³/m², 1 x 200 linee cm/ 9,5 cm³/m², 1 x 300 linee cm/ 7, 3 cm³/m², 1 x 360 linee cm/ 4, 8 cm³/m², 1 x 360 linee cm/ 5 cm³/m², 2 x 360 linee cm/ 4, 9 cm³/m², 3 x 400 linee cm/ 4, 5 cm³/m², 1 x 400 linee cm/ 4, 6 cm³/m², 1 x 160 linee cm/ 11 cm³/m², 1 x 200 linee cm/ 10 cm³/m², 1 x 280 linee cm/ 10 cm³/m², 1 x 360 linee cm/ 8 cm³/m², 1 x 460 linee cm/ 5 cm³/m², 1 x 580 linee cm/ 4 cm³/m², 1 x 140 linee cm/ 16,5 cm³/m², 1 x 140 linee cm/ 13,4 cm³/m², 1 x 200 linee cm/ 9,5 cm³/m² |
| Print Sleeves | 378 sleeves, 16 x 250mm, 16 x 260mm, 8 x 270mm, 8 x 280mm, 8 x 290mm, 8 x 300mm, 8 x 310mm, 8 x 320mm, 8 x 330mm, 8 x 340mm, 8 x 345mm, 16 x 350mm, 8 x 360mm, 8 x 375mm, 8 x 380mm, 16 x 390mm, 16 x 400mm, 8 x 410mm, 16 x 420mm, 16 x 430mm, 8 x 440mm, 8 x 450mm, 8 x 460mm, 8 x 470mm, 8 x 480mm, 8 x 490mm, 8 x 500mm, 8 x 520mm, 8 x 560mm, 8 x 580mm, 10 x 600mm, 8 x 610mm, 8 x 620mm, 8 x 640mm, 8 x 650mm, 8 x 680mm, 8 x 700mm, 8 x 730mm, 8 x 750mm |
