Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1069
- Manufacturer
- SCHIAVI BOBST
- Modello
- RIGEL
- Year
- 2001
- Number of colors
- 8
- Print possibilityes
- 4+4
- Overhaul/renovation
- Checked up: 2022 by BOBST technicians both mechanic and electric parts
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1320
- Print width (mm)
- 1270
- Min print repeat (mm)
- 430
- Max print repeat (mm)
- 1200
- Unwinder type
- Double Turret Automatic Flying Splice
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Double Turret Automatic Flying Splice
- Max reel diameter rewinder (mm)
- 800
- Drying
- Thermal Oil
- Videocamera
- Fife
- Corona treatment
- Yes (Cason) for conductive and non-conductive materials
- Web guides
- In and out (BST)
- Vyscosity control
- Gama (not in use, has to be repaired)
- Inking system
- Inking System: Ceramic Anilox + Chambered Doctor Blades
- Anilox
- 23 pieces (2x80ln/cm, 2x100ln/cm, 2x120ln/cm, 2x140ln/cm, 1x160ln/cm, 1x180ln/cm, 1x200ln/cm, 2x220ln/cm, 1x270ln/cm, 5x360ln/cm, 4x380ln/cm )
- Print Sleeves
- 40 pieces ( 8x850, 8x1000, 8x1020, 8x1050, 8x1150 )
- Print cylinders
- 8 mandrels for sleeves more than 700mm repeat and 8 adaptors for sleeves more than 900mm repeat
- Note
- Materials: LDPE, HDPE, BOPP, CPP, PET, ALU, PAPER, BIO Max Speed: 300m/min Note: Motorized print station positioning- Motorized remote controlled longitudinal and side registers, Chiller thermoregulator, Turning Cross Bar in order to print in both sides of the film (4+4) Spare Parts: Drives, Cards and Gears
| Machine Code | FL1069 |
| Manufacturer | SCHIAVI BOBST |
| Modello | RIGEL |
| Year | 2001 |
| Number of colors | 8 |
| Print possibilityes | 4+4 |
| Overhaul/renovation | Checked up: 2022 by BOBST technicians both mechanic and electric parts |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1320 |
| Print width (mm) | 1270 |
| Min print repeat (mm) | 430 |
| Max print repeat (mm) | 1200 |
| Unwinder type | Double Turret Automatic Flying Splice |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Double Turret Automatic Flying Splice |
| Max reel diameter rewinder (mm) | 800 |
| Drying | Thermal Oil |
| Videocamera | Fife |
| Corona treatment | Yes (Cason) for conductive and non-conductive materials |
| Web guides | In and out (BST) |
| Vyscosity control | Gama (not in use, has to be repaired) |
| Inking system | Inking System: Ceramic Anilox + Chambered Doctor Blades |
| Anilox | 23 pieces (2x80ln/cm, 2x100ln/cm, 2x120ln/cm, 2x140ln/cm, 1x160ln/cm, 1x180ln/cm, 1x200ln/cm, 2x220ln/cm, 1x270ln/cm, 5x360ln/cm, 4x380ln/cm ) |
| Print Sleeves | 40 pieces ( 8x850, 8x1000, 8x1020, 8x1050, 8x1150 ) |
| Print cylinders | 8 mandrels for sleeves more than 700mm repeat and 8 adaptors for sleeves more than 900mm repeat |
| Note | Materials: LDPE, HDPE, BOPP, CPP, PET, ALU, PAPER, BIO Max Speed: 300m/min Note: Motorized print station positioning- Motorized remote controlled longitudinal and side registers, Chiller thermoregulator, Turning Cross Bar in order to print in both sides of the film (4+4) Spare Parts: Drives, Cards and Gears |
