Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.
Ask more informations
- Machine Code
- FL0758
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- OLYMPIA
- Year
- 1996
- Number of colors
- 6
- Print possibilityes
- 6+0
- Gearless
- No
- Fast sleeve change
- No
- 4 motor per deck CNC position system
- No
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1200
- Min print repeat (mm)
- 320
- Max print repeat (mm)
- 950
- Unwinder type
- Turret double semiautomatic
- Max reel diameter unwinder (mm)
- 600
- Rewinder type
- Turret double semiautomatic
- Max reel diameter rewinder (mm)
- 600
- Drying
- Gas Burner
- Web guides
- Ye
- Inking system
- Ceramic anilox + doctor blade
- Anilox
- 11
- Print Sleeves
- Yes
- Print cylinders
- Yes
- Note
- Max printing speed 130m/min
Machine Code | FL0758 |
Manufacturer | WINDMÖLLER & HÖLSCHER |
Modello | OLYMPIA |
Year | 1996 |
Number of colors | 6 |
Print possibilityes | 6+0 |
Gearless | No |
Fast sleeve change | No |
4 motor per deck CNC position system | No |
Computer supervision | Yes |
Web width (mm) | 1270 |
Print width (mm) | 1200 |
Min print repeat (mm) | 320 |
Max print repeat (mm) | 950 |
Unwinder type | Turret double semiautomatic |
Max reel diameter unwinder (mm) | 600 |
Rewinder type | Turret double semiautomatic |
Max reel diameter rewinder (mm) | 600 |
Drying | Gas Burner |
Web guides | Ye |
Inking system | Ceramic anilox + doctor blade |
Anilox | 11 |
Print Sleeves | Yes |
Print cylinders | Yes |
Note | Max printing speed 130m/min |
