** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL653
- Manufacturer
- SOMAFLEX
- Modello
- MINI -E
- Year
- 2003
- Number of colors
- 8
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 850
- Print width (mm)
- 820
- Min print repeat (mm)
- 250
- Max print repeat (mm)
- 600
- Unwinder type
- Two position non stop
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones electric driers
- Videocamera
- YES
- Corona treatment
- Yes
- Web guides
- Yes
- Inking system
- 10 doctor blade chamber system . 8 pneumatic pumps. 8 ink tanks.
- Anilox
- 16 as follows: 1 x 100 L/cm ; 1x120 ;2x140 ;1x180;1x200;3x255;6x315;1x320L/cm
- Print Sleeves
- Plate sleeves 88 as follows: 8x290mm;310;320;360;380;;420;440;500;540;560;600mm
- Note
- Max mechcanical speed 250m/min Plate mounting machine Soma- Microflex S
| Machine Code | FL653 |
| Manufacturer | SOMAFLEX |
| Modello | MINI -E |
| Year | 2003 |
| Number of colors | 8 |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 850 |
| Print width (mm) | 820 |
| Min print repeat (mm) | 250 |
| Max print repeat (mm) | 600 |
| Unwinder type | Two position non stop |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones electric driers |
| Videocamera | YES |
| Corona treatment | Yes |
| Web guides | Yes |
| Inking system | 10 doctor blade chamber system . 8 pneumatic pumps. 8 ink tanks. |
| Anilox | 16 as follows: 1 x 100 L/cm ; 1x120 ;2x140 ;1x180;1x200;3x255;6x315;1x320L/cm |
| Print Sleeves | Plate sleeves 88 as follows: 8x290mm;310;320;360;380;;420;440;500;540;560;600mm |
| Note | Max mechcanical speed 250m/min Plate mounting machine Soma- Microflex S |
