GALILEO MSR25 Taglia ribobinatrice // Slitter rewinders // Converting machines // Macchine Flexo Usate // Tecno Converting 2000 S.r.l.

** SOLD **

Photo Gallery

Codice Macchina: SR402
Manufacturer: GALILEO
Modello: MSR25
Year: 2003
Larghezza lavoro (mm): 2500
Materiali: PET : 12-40mic, OPP : 15-40mic, PVC : 20-40mic, NYLON : 10-50mic, CPP : 25-100mic, LDPE : 25-65mic,
Velocità: 800m/min
Unwinder type: Shaftless
Diametro massimo bobina svolgitore: 1000
Rewinder type: Center driven with independent arms
Diametro massimo bobina avvolgitore: 1000
Descrizione avvolgitore: Rewinding stations 4 pcs. Width range 300-2500mm . Max weight 1500 Kg. Chucks 3" & 6" as follows . -4 pcs. of driven chucks 3’ +4 pcs. of non driven chucks 3’ ; 4 pcs. of driven chucks 6’ + 4 pcs. of non driven chucks 6" ; 2 pcs of pressure roll 1050mm, 2 pcs of pressure roll 1350mm, 3 pcs of pressure roll 650mm, 1 pcs of pressure roll 2500mm,1 pcs of pressure roll 600mm,1 pcs of pressure roll 1700mm Trolleys
Larghezza taglio minima: 300 mm
Coltelli: Razor blade, Cutting station : 5 pcs
Ulteriori informazioni: PLC and drivers :SIEMENS S7, Webguide Fife +/- 75mm, sensor ultrasonic Unwinder core width range 1000mm -2500mm ; min outside diam 400mm ; core diam 6" ; Electrical : Voltage : 3x400V,Frequency : 50 Hz, Max. absorbed power : 65kW, Compressed air : 6-7 bar,Noise level : 80dB (A), Tension range : 16 – 160 N/m,

Codice Macchina	SR402
Manufacturer	GALILEO
Modello	MSR25
Year	2003
Larghezza lavoro (mm)	2500
Materiali	PET : 12-40mic, OPP : 15-40mic, PVC : 20-40mic, NYLON : 10-50mic, CPP : 25-100mic, LDPE : 25-65mic,
Velocità	800m/min
Unwinder type	Shaftless
Diametro massimo bobina svolgitore	1000
Rewinder type	Center driven with independent arms
Diametro massimo bobina avvolgitore	1000
Descrizione avvolgitore	Rewinding stations 4 pcs. Width range 300-2500mm . Max weight 1500 Kg. Chucks 3" & 6" as follows . -4 pcs. of driven chucks 3’ +4 pcs. of non driven chucks 3’ ; 4 pcs. of driven chucks 6’ + 4 pcs. of non driven chucks 6" ; 2 pcs of pressure roll 1050mm, 2 pcs of pressure roll 1350mm, 3 pcs of pressure roll 650mm, 1 pcs of pressure roll 2500mm,1 pcs of pressure roll 600mm,1 pcs of pressure roll 1700mm Trolleys
Larghezza taglio minima	300 mm
Coltelli	Razor blade, Cutting station : 5 pcs
Ulteriori informazioni	PLC and drivers :SIEMENS S7, Webguide Fife +/- 75mm, sensor ultrasonic Unwinder core width range 1000mm -2500mm ; min outside diam 400mm ; core diam 6" ; Electrical : Voltage : 3x400V,Frequency : 50 Hz, Max. absorbed power : 65kW, Compressed air : 6-7 bar,Noise level : 80dB (A), Tension range : 16 – 160 N/m,
