- Codice Macchina
- EC45
- Manufacturer
- S.A.M.
- Year
- 2011
- Larghezza (mm)
- 1450
- Unità di spalmatura / accoppiamento
- 2 x extrusion coating lamination units, 2 x rotogravure coating unit with double extended driers
- Unita di spalmatura / accoppiamento 1
- Gravure coating unit for primer with double drier 2 x 3 mt - 4 fans
- Unita di spalmatura / accoppiamento 2
- Extrusion coating laminating unit with single extruder diam 90 - AC motor . Extrusion die Cloeren with 62 thermobolts , auto profile control and internal deckling Gravimetric dosing unit 4 comp MacGuire
- Unita di spalmatura / accoppiamento 3
- Gravure coating unit for primer with double drier 2 x 3 mt - 4 fans
- Unita di spalmatura / accoppiamento 4
- Extrusion coating laminating unit with coex three layer coextrusion coating lamination . Extrusion die Cloeren with 62 thermobolts , auto profile control and internal deckling Two Gravimetric dosing unit 4 comp MacGuire
- Trattamento
- Corona treaters after unwinders 1 and 2
- Descrizione svolgitore primario
- Turret automatic bi-directional roll daim 1300 mm
- Descrizione svolgitore secondario
- Turret automatic bi-directional roll daim 1300 mm
- 3rd unwinder description
- Turret automatic bi-directional roll daim 1300 mm
- Descrizione avvolgitore
- Turret automatic
- Velocità
- 300 m/min
- Ulteriori informazioni
- 2 Corona Treater Mero , driven , ceramic Die Head Cloeren With Auto Thinckness Control 62 Screws Internal Deckling System Two New Thinkness Control Thermofischer 2 Spare Chill Roller Diam 1000 Both Un Its Also Laminating
| Codice Macchina | EC45 |
| Manufacturer | S.A.M. |
| Year | 2011 |
| Larghezza (mm) | 1450 |
| Unità di spalmatura / accoppiamento | 2 x extrusion coating lamination units, 2 x rotogravure coating unit with double extended driers |
| Unita di spalmatura / accoppiamento 1 | Gravure coating unit for primer with double drier 2 x 3 mt - 4 fans |
| Unita di spalmatura / accoppiamento 2 | Extrusion coating laminating unit with single extruder diam 90 - AC motor . Extrusion die Cloeren with 62 thermobolts , auto profile control and internal deckling Gravimetric dosing unit 4 comp MacGuire |
| Unita di spalmatura / accoppiamento 3 | Gravure coating unit for primer with double drier 2 x 3 mt - 4 fans |
| Unita di spalmatura / accoppiamento 4 | Extrusion coating laminating unit with coex three layer coextrusion coating lamination . Extrusion die Cloeren with 62 thermobolts , auto profile control and internal deckling Two Gravimetric dosing unit 4 comp MacGuire |
| Trattamento | Corona treaters after unwinders 1 and 2 |
| Descrizione svolgitore primario | Turret automatic bi-directional roll daim 1300 mm |
| Descrizione svolgitore secondario | Turret automatic bi-directional roll daim 1300 mm |
| 3rd unwinder description | Turret automatic bi-directional roll daim 1300 mm |
| Descrizione avvolgitore | Turret automatic |
| Velocità | 300 m/min |
| Ulteriori informazioni | 2 Corona Treater Mero , driven , ceramic Die Head Cloeren With Auto Thinckness Control 62 Screws Internal Deckling System Two New Thinkness Control Thermofischer 2 Spare Chill Roller Diam 1000 Both Un Its Also Laminating |
