- Code Machine
- SA41
- Fabricant
- WINDMÖLLER & HÖLSCHER
- Modello
- Bottomer AD2360/16
- Année
- 1972
- Taper
- Bottomer
- Note
- W&H Bottomer products specifications , production , and power consumption Tube width 30 - 70 cm Bag length Stepped cut 37 - 120 cm Bottom center distance 30 - 110 cm Bottom width Flush cut 7 - 16 cm Bottom width Stepped end 7 - 15 cm Production speed depending on paper quality and size 130 bags per minute Power 400V - 50 Hz. Bottomer AD 2360/16 is equipped with the following units Rotary feeder Tube aligner Diverter for removing incorrectly fed tubes Diagonal creasing and needle vent hole arrangements Bottom center creasing stations with slitting arrangements for bottom flaps Bottom opening station Bottom creasing station Bottom turning station Bottom closing station Bottom pasting 1 valve unit Press station Counting and packeting station
| Code Machine | SA41 |
| Fabricant | WINDMÖLLER & HÖLSCHER |
| Modello | Bottomer AD2360/16 |
| Année | 1972 |
| Taper | Bottomer |
| Note | W&H Bottomer products specifications , production , and power consumption Tube width 30 - 70 cm Bag length Stepped cut 37 - 120 cm Bottom center distance 30 - 110 cm Bottom width Flush cut 7 - 16 cm Bottom width Stepped end 7 - 15 cm Production speed depending on paper quality and size 130 bags per minute Power 400V - 50 Hz. Bottomer AD 2360/16 is equipped with the following units Rotary feeder Tube aligner Diverter for removing incorrectly fed tubes Diagonal creasing and needle vent hole arrangements Bottom center creasing stations with slitting arrangements for bottom flaps Bottom opening station Bottom creasing station Bottom turning station Bottom closing station Bottom pasting 1 valve unit Press station Counting and packeting station |
