- Code Machine
- FS33
- Fabricant
- HONSEL
- Modello
- PHOENIX 26
- Année
- 1981
- Overhaul/renovation
- Overhauled in 2015
- Width (mm)
- 1000
- Materials
- Paper 30 - 120 g/m2
- Bag length (mm)
- 100-480
- Bag width (mm)
- 60-260
- Bottom width (mm)
- 50-150
- Cycle / min
- 300 - 600 bags/min
- Note
- Cutting lenght (mm) : 120 - 500 Electricity: Simens 5 kW Accessories: -10 forming plates (mm): 85, 100, 105, 120, 130, 140, 145, 170, 190, 230 -Knives 2 / 300 min.Knives 4 / 600 min. Additional tools : Tool bag width (mm) : 100, 105, 120, 130, 140, 145, 170, 190, 230. Printer: HONSEL & CO (2+1colors + 1 optional) Anilox roller : 100 Lpi Printing cylinders (mm): 2x220, 2x240, 3x270, 2x320, 1x360, 2x440 Length: 7,5 - 8 m Width: 1.6 m Height: 1.5 m.
Code Machine | FS33 |
Fabricant | HONSEL |
Modello | PHOENIX 26 |
Année | 1981 |
Overhaul/renovation | Overhauled in 2015 |
Width (mm) | 1000 |
Materials | Paper 30 - 120 g/m2 |
Bag length (mm) | 100-480 |
Bag width (mm) | 60-260 |
Bottom width (mm) | 50-150 |
Cycle / min | 300 - 600 bags/min |
Note | Cutting lenght (mm) : 120 - 500 Electricity: Simens 5 kW Accessories: -10 forming plates (mm): 85, 100, 105, 120, 130, 140, 145, 170, 190, 230 -Knives 2 / 300 min.Knives 4 / 600 min. Additional tools : Tool bag width (mm) : 100, 105, 120, 130, 140, 145, 170, 190, 230. Printer: HONSEL & CO (2+1colors + 1 optional) Anilox roller : 100 Lpi Printing cylinders (mm): 2x220, 2x240, 3x270, 2x320, 1x360, 2x440 Length: 7,5 - 8 m Width: 1.6 m Height: 1.5 m. |
