1 couches PRANDI Machine de extrusion de film cast

Code Machine
CA017
Fabricant
PRANDI
Année
1984
Number of layers
1
Material
CPP
Film width (mm)
2000
Output (Kg/h)
350 kg/h gross output
Screw diam 1
160
Head description
fixed extrusion die manual adjustment,
Die width (mm)
2300
Chill roll unit
Head: manual adjustment, air and smoke suction by fan and encapsulating hood\r\nChill roll: with two cylinders (diameter 750 and 300 mm UNION SELECT width 2400 mm, independent thermoregulation units for the two cylinders, rubber-covered pressure roller and brush cleaner; Thickness : 25 to 250 micron ;edge pinning system by air;
Thickness controll system
Electronic system thickness mesurement;
Corona treatment
single-face corona treatment unit, FERRARINI & BENELLI
Web guide
E+L
Rewinder max reel diameter (mm)
800
Rewinder description
TURRET winder , transversal guillotine cut, control device: PLC Siemens
Note
In line slitting;automatic hopper loader (without dosing systems);air and smoke suction by fan and enca;side-slip unit ERHARDT + LEIMER;motor-drrevolver-type winder with lay-on roller and contact carriage, transversal guillotine cut, max. reel diameter 800 mmiven haul-off unit and trimming group with 4 rotary blades;control device: PLC Siemens
Code Machine CA017
Fabricant PRANDI
Année 1984
Number of layers 1
Material CPP
Film width (mm) 2000
Output (Kg/h) 350 kg/h gross output
Screw diam 1 160
Head description fixed extrusion die manual adjustment,
Die width (mm) 2300
Chill roll unit Head: manual adjustment, air and smoke suction by fan and encapsulating hood\r\nChill roll: with two cylinders (diameter 750 and 300 mm UNION SELECT width 2400 mm, independent thermoregulation units for the two cylinders, rubber-covered pressure roller and brush cleaner; Thickness : 25 to 250 micron ;edge pinning system by air;
Thickness controll system Electronic system thickness mesurement;
Corona treatment single-face corona treatment unit, FERRARINI & BENELLI
Web guide E+L
Rewinder max reel diameter (mm) 800
Rewinder description TURRET winder , transversal guillotine cut, control device: PLC Siemens
Note In line slitting;automatic hopper loader (without dosing systems);air and smoke suction by fan and enca;side-slip unit ERHARDT + LEIMER;motor-drrevolver-type winder with lay-on roller and contact carriage, transversal guillotine cut, max. reel diameter 800 mmiven haul-off unit and trimming group with 4 rotary blades;control device: PLC Siemens
** SOLD **
