- Code Machine
- FL1182
- Fabricant
- COMEXI
- Modello
- F4
- Année
- 2014
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 920
- Print width (mm)
- 870
- Min print repeat (mm)
- 260
- Max print repeat (mm)
- 600
- Unwinder type
- Shaftless
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Shaftless
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Electric
- Videocamera
- AVT Printvision Jupiter 2.8
- Web guides
- BST
- Vyscosity control
- Yes automatic by Inkspec IIS
- Washing system
- Yes
- Inking system
- Closed chamber doctor blades
- Anilox
- 18 ceramic anilox sleeevs : 7 x 420 L/cm , 1x 380 L/cm, 1x 280 L/cm, 1x 220 L/cm , 1x 200 L/cm, 1x 180 L/cm, 2x 160 L/cm , 1x 140 L/cm, 2x 120 L/cm, 1x 80 L/cm
- Print Sleeves
- 192 sleeves : 22 x 265mm, 8 x 275mm, 8 x 285mm, 10 x 300mm, 8 x 310mm, 12 x 325mm, 8 x 340mm, 10 x 350mm, 10 x 360mm, 12 x 380mm, 8 x 400mm, 18 x 420mm, 9 x 440mm, 8 x 450mm, 15 x 460mm, 12 x 480mm, 14 x 500mm
- Note
- Plate mounter Bieffebi
| Code Machine | FL1182 |
| Fabricant | COMEXI |
| Modello | F4 |
| Année | 2014 |
| Number of colors | 8 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 920 |
| Print width (mm) | 870 |
| Min print repeat (mm) | 260 |
| Max print repeat (mm) | 600 |
| Unwinder type | Shaftless |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Shaftless |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | Electric |
| Videocamera | AVT Printvision Jupiter 2.8 |
| Web guides | BST |
| Vyscosity control | Yes automatic by Inkspec IIS |
| Washing system | Yes |
| Inking system | Closed chamber doctor blades |
| Anilox | 18 ceramic anilox sleeevs : 7 x 420 L/cm , 1x 380 L/cm, 1x 280 L/cm, 1x 220 L/cm , 1x 200 L/cm, 1x 180 L/cm, 2x 160 L/cm , 1x 140 L/cm, 2x 120 L/cm, 1x 80 L/cm |
| Print Sleeves | 192 sleeves : 22 x 265mm, 8 x 275mm, 8 x 285mm, 10 x 300mm, 8 x 310mm, 12 x 325mm, 8 x 340mm, 10 x 350mm, 10 x 360mm, 12 x 380mm, 8 x 400mm, 18 x 420mm, 9 x 440mm, 8 x 450mm, 15 x 460mm, 12 x 480mm, 14 x 500mm |
| Note | Plate mounter Bieffebi |
