- Code Machine
- FL731
- Fabricant
- UTECO
- Modello
- ONYX
- Année
- 2012
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- No
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones Four fans , 4 mt tunnel
- Videocamera
- Yes AVT with register control
- Web guides
- Yes in and out
- Vyscosity control
- Yes automatic
- Washing system
- Yes
- Inking system
- Closed chamber doctor blades
- Anilox
- 23 ceramic anilox sleeves
- Print Sleeves
- as available 200
- Note
- Plate mounter AV Flexologic
| Code Machine | FL731 |
| Fabricant | UTECO |
| Modello | ONYX |
| Année | 2012 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | No |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1250 |
| Print width (mm) | 1200 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret Automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones Four fans , 4 mt tunnel |
| Videocamera | Yes AVT with register control |
| Web guides | Yes in and out |
| Vyscosity control | Yes automatic |
| Washing system | Yes |
| Inking system | Closed chamber doctor blades |
| Anilox | 23 ceramic anilox sleeves |
| Print Sleeves | as available 200 |
| Note | Plate mounter AV Flexologic |
