- Código Máquina
- LA203
- Constructor
- NORDMECCANICA
- Modello
- SUPER SIMPLEX COMBI
- Año
- 1996
- Application
- Duplex lamination
- Type of lamination/coating
- COMBI / INTECHANGEABLE TROLLEY
- Working width (mm)
- 1300
- Materials
- in the oven ALU ,PET, PP -other side PE PET PP, paper
- First unwinder type
- Single position shaftless
- Max diameter reel unwinder
- 800
- Secondary unwinder type
- Single position shaftless
- Max diameter reel unwinder
- 800
- Rewinder type
- Single
- Max diameter reel rewinder
- 800
- Coating unit
- available with rotogravure coating unit, suitable for solvent based and waterbased coatings. Solventless trolley not available
- Drying
- Gas burner
- pumping mixing unit
- Yes 2 component for solventless
- Corona treatment
- Mero
- Note
- Ceramic adhesive's spreader lamination type. Number and sizes airshafts 70mm;76mm;152mm Edge guide with photocell Spare :1 unwind reel's motor ; some electronic boards, 4/5 adhesive's sleeves (to be agreed for sizes)
| Código Máquina | LA203 |
| Constructor | NORDMECCANICA |
| Modello | SUPER SIMPLEX COMBI |
| Año | 1996 |
| Application | Duplex lamination |
| Type of lamination/coating | COMBI / INTECHANGEABLE TROLLEY |
| Working width (mm) | 1300 |
| Materials | in the oven ALU ,PET, PP -other side PE PET PP, paper |
| First unwinder type | Single position shaftless |
| Max diameter reel unwinder | 800 |
| Secondary unwinder type | Single position shaftless |
| Max diameter reel unwinder | 800 |
| Rewinder type | Single |
| Max diameter reel rewinder | 800 |
| Coating unit | available with rotogravure coating unit, suitable for solvent based and waterbased coatings. Solventless trolley not available |
| Drying | Gas burner |
| pumping mixing unit | Yes 2 component for solventless |
| Corona treatment | Mero |
| Note | Ceramic adhesive's spreader lamination type. Number and sizes airshafts 70mm;76mm;152mm Edge guide with photocell Spare :1 unwind reel's motor ; some electronic boards, 4/5 adhesive's sleeves (to be agreed for sizes) |
