- Código Máquina
- LA175
- Constructor
- NORDMECCANICA
- Modello
- TRIPLEX COMBI
- Año
- 2006
- Application
- Triplex lamination
- Type of lamination/coating
- COMBI / INTECHANGEABLE TROLLEY
- Working width (mm)
- 1300
- Materials
- all plastic film and paper , alu foil
- Speed
- 400 mpm
- First unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Third unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Rewinder type
- Turret automatic
- Max diameter reel rewinder
- 1000
- Coating unit
- solvent based trolley
- Second Coating unitr
- solvent based, solventless, cold seal coating
- Drying
- 2 coating sections each one two drying zones , three fans 7,5 mt driers , thermo oil heaters, automatic recirculation wih LEL control by NIRA
- Register controll
- yes on second coating unit for cold seal
- pumping mixing unit
- World mix
- Corona treatment
- 2 corona treaters Ferrarini Benelli complete with ozone exhaust and treatment
- Note
- Viscosity control for solvent based adhesive. 4 heating units for solventless trolley. 2 chillers Frigosystem
| Código Máquina | LA175 |
| Constructor | NORDMECCANICA |
| Modello | TRIPLEX COMBI |
| Año | 2006 |
| Application | Triplex lamination |
| Type of lamination/coating | COMBI / INTECHANGEABLE TROLLEY |
| Working width (mm) | 1300 |
| Materials | all plastic film and paper , alu foil |
| Speed | 400 mpm |
| First unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Third unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Turret automatic |
| Max diameter reel rewinder | 1000 |
| Coating unit | solvent based trolley |
| Second Coating unitr | solvent based, solventless, cold seal coating |
| Drying | 2 coating sections each one two drying zones , three fans 7,5 mt driers , thermo oil heaters, automatic recirculation wih LEL control by NIRA |
| Register controll | yes on second coating unit for cold seal |
| pumping mixing unit | World mix |
| Corona treatment | 2 corona treaters Ferrarini Benelli complete with ozone exhaust and treatment |
| Note | Viscosity control for solvent based adhesive. 4 heating units for solventless trolley. 2 chillers Frigosystem |
