- Código Máquina
- LA435
- Constructor
- REMAK
- Modello
- MIZAR Solventless
- Año
- 2017
- Application
- Duplex lamination
- Type of lamination/coating
- Solventless
- Working width (mm)
- 1600
- Materials
- Films (Bopp 12-80my, pet 12-30my, PE 30-200my, others) All foil 7-40 my, paper and board up to 350 gsm:
- Speed
- 350 mpm
- First unwinder type
- Shaftless driven
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- Shaftless driven
- Max diameter reel unwinder
- 1000
- Rewinder type
- Shaftless driven
- Max diameter reel rewinder
- 1000
- Coating unit
- solventless 5 rolle - staggered
- pumping mixing unit
- Machine Equipped with mono component glue unit (for film + paper) Make Remak Monomix. We can offer as optional Dopag 2 component mixing pumping unit year 2018 for 13.000 Eur
- Corona treatment
- No
- Note
- 3 Heating and temp.control units for coating rollers and lamination nip Three roller type lamination nip with back up roller In line slitting system Helios
| Código Máquina | LA435 |
| Constructor | REMAK |
| Modello | MIZAR Solventless |
| Año | 2017 |
| Application | Duplex lamination |
| Type of lamination/coating | Solventless |
| Working width (mm) | 1600 |
| Materials | Films (Bopp 12-80my, pet 12-30my, PE 30-200my, others) All foil 7-40 my, paper and board up to 350 gsm: |
| Speed | 350 mpm |
| First unwinder type | Shaftless driven |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | Shaftless driven |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Shaftless driven |
| Max diameter reel rewinder | 1000 |
| Coating unit | solventless 5 rolle - staggered |
| pumping mixing unit | Machine Equipped with mono component glue unit (for film + paper) Make Remak Monomix. We can offer as optional Dopag 2 component mixing pumping unit year 2018 for 13.000 Eur |
| Corona treatment | No |
| Note | 3 Heating and temp.control units for coating rollers and lamination nip Three roller type lamination nip with back up roller In line slitting system Helios |
