- Código Máquina
- LA302
- Constructor
- GHEZZI & ANNONI
- Modello
- HOTMELT
- Año
- 2002
- Application
- Coating
- Type of lamination/coating
- Hot melt
- Working width (mm)
- 1650
- Materials
- BOPP, Celofan, Masking tape, Polythene Strapping, Reinforced
- Speed
- Mechanical speed : 350 m/min Machine running speed: 300 m/min (18g/m2 adhesive)
- First unwinder type
- Jumbo
- Max diameter reel unwinder
- 1000
- Rewinder type
- Jumbo
- Max diameter reel rewinder
- 1000
- Coating unit
- 1 by Mayer bar
- Second Coating unitr
- 2 extruders
- Drying
- Thermic oil - Electric for die
- Note
- Winder was replaced in 2007 with a newer one scrapless. Automatic duplex Unwinder auto splice Release Unit completed with TRESU closed Dr Blade Adhesive coating die ( Simplas ) Adhesive preparation Unit Automatic duplex Rewinder auto splice LEL System + LEL Alert Hotmelt Adhesive filter : mahle system Edge guide unit : 1-before coating die 1-before rewinder Hotmelt adhesive: 12g/m2 – 120 g/m2 Temperature: Between 100-200°C Adhesive : Mixed with SIS rubber and SBS Viscosity: Between 10,000 – 100,000 CPS Release Drying Tunnels; 1 Oven with a total heating power 350.000Kcal/h Total Air flow: 18,000m3/h Max working temperature: 120°C Entrance temperature: 20°C Air absorption capacity: 14,000Nm3/h approx.
| Código Máquina | LA302 |
| Constructor | GHEZZI & ANNONI |
| Modello | HOTMELT |
| Año | 2002 |
| Application | Coating |
| Type of lamination/coating | Hot melt |
| Working width (mm) | 1650 |
| Materials | BOPP, Celofan, Masking tape, Polythene Strapping, Reinforced |
| Speed | Mechanical speed : 350 m/min Machine running speed: 300 m/min (18g/m2 adhesive) |
| First unwinder type | Jumbo |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Jumbo |
| Max diameter reel rewinder | 1000 |
| Coating unit | 1 by Mayer bar |
| Second Coating unitr | 2 extruders |
| Drying | Thermic oil - Electric for die |
| Note | Winder was replaced in 2007 with a newer one scrapless. Automatic duplex Unwinder auto splice Release Unit completed with TRESU closed Dr Blade Adhesive coating die ( Simplas ) Adhesive preparation Unit Automatic duplex Rewinder auto splice LEL System + LEL Alert Hotmelt Adhesive filter : mahle system Edge guide unit : 1-before coating die 1-before rewinder Hotmelt adhesive: 12g/m2 – 120 g/m2 Temperature: Between 100-200°C Adhesive : Mixed with SIS rubber and SBS Viscosity: Between 10,000 – 100,000 CPS Release Drying Tunnels; 1 Oven with a total heating power 350.000Kcal/h Total Air flow: 18,000m3/h Max working temperature: 120°C Entrance temperature: 20°C Air absorption capacity: 14,000Nm3/h approx. |
