3 capas ADTECH PROVERA Extrusora de film

Código Máquina
CA132
Constructor
ADTECH PROVERA
Año
2009
Number of layers
3
Film structure
ABC
Material
Stretch film LLDPE
Film width (mm)
2000
Speed (m/min)
600
Output (Kg/h)
about 400 tons of stretch film per month
Extruder 1 Layer ref:
A
Screw diam 1
80mm
Description 1
L/D30, Hydraulic screen changer, AC motor, volumetric doser 2 comp
Extruder 2 Layer ref:
B
Screw diam 2
160mm
Description 2
L/D30, Hydraulic screen changer, AC motor
Extruder 3 Layer ref:
C
Screw diam 3
80mm
Description 3
L/D30, Hydraulic screen changer, AC motor, volumetric doser 2 comp
Head description
Automatic die with thermo bolts thickness profile control. Dual chamber vacuum box
Chill roll unit
first chill roll 1000mm diam, second 450mm diam, width 2550mm
Thickness controll system
Automatic thickness controll system. Gauge with x rays
Web guide
yes
Rewinder description
Turret type. Suitable for jumbo and machine rolls. Automatic reels unloading
Note
in line edge trim recovery system
Código Máquina CA132
Constructor ADTECH PROVERA
Año 2009
Number of layers 3
Film structure ABC
Material Stretch film LLDPE
Film width (mm) 2000
Speed (m/min) 600
Output (Kg/h) about 400 tons of stretch film per month
Extruder 1 Layer ref: A
Screw diam 1 80mm
Description 1 L/D30, Hydraulic screen changer, AC motor, volumetric doser 2 comp
Extruder 2 Layer ref: B
Screw diam 2 160mm
Description 2 L/D30, Hydraulic screen changer, AC motor
Extruder 3 Layer ref: C
Screw diam 3 80mm
Description 3 L/D30, Hydraulic screen changer, AC motor, volumetric doser 2 comp
Head description Automatic die with thermo bolts thickness profile control. Dual chamber vacuum box
Chill roll unit first chill roll 1000mm diam, second 450mm diam, width 2550mm
Thickness controll system Automatic thickness controll system. Gauge with x rays
Web guide yes
Rewinder description Turret type. Suitable for jumbo and machine rolls. Automatic reels unloading
Note in line edge trim recovery system
