- Código Máquina
- RO267
- Constructor
- S.A.M.
- Modello
- Sprinter 350
- Año
- 2014
- Number of colors
- 10
- Drive
- Electronic shaft
- Trolley system
- Yes
- Web width (mm)
- 1320
- Print width (mm)
- 1300
- Drying specifications
- Dryer 1 - 100 C max. temp 2.8 meter electric dryer Dryer 2 - 8 - 100 C max. temp 2.4 meter electric dryer Dryer 9 - 100 C max. temp 2 meter + 3.3 meter electric dryer Dryer 10 - 100 C max. temp 5.4 meter electric dryer
- Unwinder type
- Turret, 3" & 6" cores, shaftless and shafted, dancer, auto dual direction splicing, manual sidelay
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret, 3" & 6" cores, shaftless and shafted, dancer, auto dual direciton roll change, manual sidelay, layon roll, pressure roll
- Max reel diameter rewinder (mm)
- 1000
- Videocamera
- Defect detection System Jupiter AVT
- Note
- Fife web guide Additonal trolleys AC Vector drives Spare doctor blade holders Cylinder cleaning device Anti static brushes 1 Turn Bar 1 Outfeed Unit - Pull rols, dancer, Indramat servo 1 Infeed Unit - Pull rols, load cell, pre-heat dryer, Indramat servo Materials: OPP - 15 - 50micron CPP - 15 - 70micron Polyester - 9 - 25micron O-nylon - 12- 25micron LDPE, LLDPE - 30 -100micron Paper - 40 - 80gsm
| Código Máquina | RO267 |
| Constructor | S.A.M. |
| Modello | Sprinter 350 |
| Año | 2014 |
| Number of colors | 10 |
| Drive | Electronic shaft |
| Trolley system | Yes |
| Web width (mm) | 1320 |
| Print width (mm) | 1300 |
| Drying specifications | Dryer 1 - 100 C max. temp 2.8 meter electric dryer Dryer 2 - 8 - 100 C max. temp 2.4 meter electric dryer Dryer 9 - 100 C max. temp 2 meter + 3.3 meter electric dryer Dryer 10 - 100 C max. temp 5.4 meter electric dryer |
| Unwinder type | Turret, 3" & 6" cores, shaftless and shafted, dancer, auto dual direction splicing, manual sidelay |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret, 3" & 6" cores, shaftless and shafted, dancer, auto dual direciton roll change, manual sidelay, layon roll, pressure roll |
| Max reel diameter rewinder (mm) | 1000 |
| Videocamera | Defect detection System Jupiter AVT |
| Note | Fife web guide Additonal trolleys AC Vector drives Spare doctor blade holders Cylinder cleaning device Anti static brushes 1 Turn Bar 1 Outfeed Unit - Pull rols, dancer, Indramat servo 1 Infeed Unit - Pull rols, load cell, pre-heat dryer, Indramat servo Materials: OPP - 15 - 50micron CPP - 15 - 70micron Polyester - 9 - 25micron O-nylon - 12- 25micron LDPE, LLDPE - 30 -100micron Paper - 40 - 80gsm |
