- Código Máquina
- FL1153
- Constructor
- UTECO
- Modello
- ONYX 808
- Año
- 2013
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 330
- Max print repeat (mm)
- 800
- Unwinder type
- Automatic Turret
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Automatic Turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 gas burners, 2 zones with independent ventilation
- Videocamera
- Yes Grafikontrol with defect control
- Corona treatment
- No
- Web guides
- FIFE
- Vyscosity control
- yes Inkspec
- Washing system
- yes automatic
- Inking system
- Chamber doctor blades - pneumatic pumps
- Anilox
- 11 approx.
- Print Sleeves
- 56
| Código Máquina | FL1153 |
| Constructor | UTECO |
| Modello | ONYX 808 |
| Año | 2013 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1250 |
| Print width (mm) | 1200 |
| Min print repeat (mm) | 330 |
| Max print repeat (mm) | 800 |
| Unwinder type | Automatic Turret |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Automatic Turret |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 gas burners, 2 zones with independent ventilation |
| Videocamera | Yes Grafikontrol with defect control |
| Corona treatment | No |
| Web guides | FIFE |
| Vyscosity control | yes Inkspec |
| Washing system | yes automatic |
| Inking system | Chamber doctor blades - pneumatic pumps |
| Anilox | 11 approx. |
| Print Sleeves | 56 |
