- Código Máquina
- FL790
- Constructor
- FLEXOTECNICA
- Modello
- TACHYS
- Año
- 1998
- Number of colors
- 8
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- No
- Computer supervision
- Yes
- Web width (mm)
- 1050
- Print width (mm)
- 1000
- Min print repeat (mm)
- 300
- Max print repeat (mm)
- 650
- Unwinder type
- Flying splice
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Flying splice
- Max reel diameter rewinder (mm)
- 800
- Drying
- Gas
- Videocamera
- Yes
- Web guides
- Yes
- Washing system
- No
- Inking system
- Solvent based. Chamber Doctor Blade
- Anilox
- 20 as follows: 2x140L ;3x160L ;1x240L;4x400L; 1x14Vx100L ; 1x12Vx180L ; 2x10Vx200L;1x6Vx260L;1x8Vx280L;2x5,4Vx320L;2x490Vx320L
- Print Sleeves
- 237 as follows: 11x300;8x310330,340,400,460,480,520,560,640 ; 7x320; 10x350,; 9x360, 22x380,4x390,13x410; 12x420; 16x430,450,; 24x440; 15x500m-m
- Note
- Speed: 250m/min Pre register automatic Computer system type Fast one
| Código Máquina | FL790 |
| Constructor | FLEXOTECNICA |
| Modello | TACHYS |
| Año | 1998 |
| Number of colors | 8 |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | No |
| Computer supervision | Yes |
| Web width (mm) | 1050 |
| Print width (mm) | 1000 |
| Min print repeat (mm) | 300 |
| Max print repeat (mm) | 650 |
| Unwinder type | Flying splice |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Flying splice |
| Max reel diameter rewinder (mm) | 800 |
| Drying | Gas |
| Videocamera | Yes |
| Web guides | Yes |
| Washing system | No |
| Inking system | Solvent based. Chamber Doctor Blade |
| Anilox | 20 as follows: 2x140L ;3x160L ;1x240L;4x400L; 1x14Vx100L ; 1x12Vx180L ; 2x10Vx200L;1x6Vx260L;1x8Vx280L;2x5,4Vx320L;2x490Vx320L |
| Print Sleeves | 237 as follows: 11x300;8x310330,340,400,460,480,520,560,640 ; 7x320; 10x350,; 9x360, 22x380,4x390,13x410; 12x420; 16x430,450,; 24x440; 15x500m-m |
| Note | Speed: 250m/min Pre register automatic Computer system type Fast one |
