BOBST FISCHER & KRECKE 20 / 6 CS flexo printing machine 10 colors

** SOLD **

Flexo CI presses use a central drum which is common to all colours as counter impression roll.

Ask more informations
about a similar one
Machine Code
FL739
Manufacturer
BOBST FISCHER & KRECKE
Model
20 / 6 CS
Year
2015
Number of colors
10
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1750
Print width (mm)
1700
Min print repeat (mm)
360
Max print repeat (mm)
1200
Unwinder type
TURRET
Max reel diameter unwinder (mm)
1000
Rewinder type
TURRET
Max reel diameter rewinder (mm)
1000
Drying
2 ZONES 2 GAS BURNERS 4 FANS
Videocamera
Eltromat high resolution camera; Eltromat 100% inspection system
Corona treatment
MERO Web MR/B10K0P3IGBT
Web guides
yes
Vyscosity control
Automatic
Washing system
Automatic
Inking system
closed chamber doctor blades
Anilox
Sets available
Print Sleeves
approx 300, with GPS chip
Additional information
SMART GPS SYSTEM COMMISSIONED IN 2016 MODEL 26 CS IONTIS Web Treatment Unit SMC IDFA37E Refrigeration Air Dryer TECHNOTRANS Bete.t Chiller PROTEC Series 21000 Fire Suppression OPTIMA Environmental Protection
Machine Code FL739
Manufacturer BOBST FISCHER & KRECKE
Model 20 / 6 CS
Year 2015
Number of colors 10
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1750
Print width (mm) 1700
Min print repeat (mm) 360
Max print repeat (mm) 1200
Unwinder type TURRET
Max reel diameter unwinder (mm) 1000
Rewinder type TURRET
Max reel diameter rewinder (mm) 1000
Drying 2 ZONES 2 GAS BURNERS 4 FANS
Videocamera Eltromat high resolution camera; Eltromat 100% inspection system
Corona treatment MERO Web MR/B10K0P3IGBT
Web guides yes
Vyscosity control Automatic
Washing system Automatic
Inking system closed chamber doctor blades
Anilox Sets available
Print Sleeves approx 300, with GPS chip
Additional information SMART GPS SYSTEM COMMISSIONED IN 2016 MODEL 26 CS IONTIS Web Treatment Unit SMC IDFA37E Refrigeration Air Dryer TECHNOTRANS Bete.t Chiller PROTEC Series 21000 Fire Suppression OPTIMA Environmental Protection
