- Maschinencode
- LA538
- Hersteller
- ROTOMEC
- Modello
- ROTOPAK 3000-S/1200/400
- Baujahr
- 2002
- Application
- Coating
- Type of lamination/coating
- SOLVENT / WATER BASED
- Working width (mm)
- 1220
- Speed
- 525mpm
- First unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Third unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Rewinder type
- Turret automatic
- Max diameter reel rewinder
- 1000
- Drying
- All 3 units are double hood, each with one supply fan and one exhaust fan.Drying Heat Source - Steam
- Note
- 3-station (2 reversible, 1 hotmelt) Drive: Independent Drive Machine HMI: Factory Talk, Windows 10 PLC: Siemens 6ES7414-2XJ01-0AB0, Profibus Drives: Siemens Dilution Control: Yes
| Maschinencode | LA538 |
| Hersteller | ROTOMEC |
| Modello | ROTOPAK 3000-S/1200/400 |
| Baujahr | 2002 |
| Application | Coating |
| Type of lamination/coating | SOLVENT / WATER BASED |
| Working width (mm) | 1220 |
| Speed | 525mpm |
| First unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Third unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Turret automatic |
| Max diameter reel rewinder | 1000 |
| Drying | All 3 units are double hood, each with one supply fan and one exhaust fan.Drying Heat Source - Steam |
| Note | 3-station (2 reversible, 1 hotmelt) Drive: Independent Drive Machine HMI: Factory Talk, Windows 10 PLC: Siemens 6ES7414-2XJ01-0AB0, Profibus Drives: Siemens Dilution Control: Yes |
