- Maschinencode
- LA511
- Hersteller
- BOBST ROTOMEC
- Baujahr
- 2003
- Application
- Triplex lamination
- Type of lamination/coating
- COMBI / INTECHANGEABLE TROLLEY
- Working width (mm)
- 1300
- Materials
- Films. Aluminium, paper
- Speed
- 350/min
- First unwinder type
- Turret
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- Turret
- Max diameter reel unwinder
- 1000
- Third unwinder type
- Turret
- Max diameter reel unwinder
- 1000
- Rewinder type
- Turret
- Max diameter reel rewinder
- 1000
- Coating unit
- Interchangeable trolley system. Available with 3 roller coating system(offset-gravure) Horizontal drying oven
- Second Coating unitr
- Interchangeable trolley system. Available with 3 roller coating system(offset-gravure) Horizontal drying oven
- Drying
- Heat source thermal oil. 2 horizontal drying tunnels. Each tunnel is 12m length (24m total). Each tunnel is composed of 4 hoods with independent fan and heater. Total 12 hoods
- Corona treatment
- 3 x ME.RO MRIB 8K
- Note
- Application is Triplex lamination, double lacquering, or lamination + coating - Inline mechanical perforation system - CO2 fire suppression system - PLC SIEMENS S7 - LEL system OPERATIONAL - 2 x NDC coating thickness gauges, via IR. Model Infragauge Pro - Turning bar
| Maschinencode | LA511 |
| Hersteller | BOBST ROTOMEC |
| Baujahr | 2003 |
| Application | Triplex lamination |
| Type of lamination/coating | COMBI / INTECHANGEABLE TROLLEY |
| Working width (mm) | 1300 |
| Materials | Films. Aluminium, paper |
| Speed | 350/min |
| First unwinder type | Turret |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | Turret |
| Max diameter reel unwinder | 1000 |
| Third unwinder type | Turret |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Turret |
| Max diameter reel rewinder | 1000 |
| Coating unit | Interchangeable trolley system. Available with 3 roller coating system(offset-gravure) Horizontal drying oven |
| Second Coating unitr | Interchangeable trolley system. Available with 3 roller coating system(offset-gravure) Horizontal drying oven |
| Drying | Heat source thermal oil. 2 horizontal drying tunnels. Each tunnel is 12m length (24m total). Each tunnel is composed of 4 hoods with independent fan and heater. Total 12 hoods |
| Corona treatment | 3 x ME.RO MRIB 8K |
| Note | Application is Triplex lamination, double lacquering, or lamination + coating - Inline mechanical perforation system - CO2 fire suppression system - PLC SIEMENS S7 - LEL system OPERATIONAL - 2 x NDC coating thickness gauges, via IR. Model Infragauge Pro - Turning bar |
