- Maschinencode
- FL831
- Hersteller
- UTECO
- Modello
- ONYX 810
- Baujahr
- 2011
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1650
- Print width (mm)
- 1600
- Min print repeat (mm)
- 450
- Max print repeat (mm)
- 1100
- Unwinder type
- Turret automatic
- Rewinder type
- Turret automatic
- Drying
- 2 zones - 4 fans - 5 mt tunnel - 2 gas burners - automatic recirculation system with LEL control
- Videocamera
- Yes
- Corona treatment
- yes
- Web guides
- Yes in and out
- Vyscosity control
- Yes
- Washing system
- Yes automatic
- Inking system
- Closed chamber doctor blades
- Anilox
- 12 ceramic anilox sleeves
- Print Sleeves
- 80
| Maschinencode | FL831 |
| Hersteller | UTECO |
| Modello | ONYX 810 |
| Baujahr | 2011 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1650 |
| Print width (mm) | 1600 |
| Min print repeat (mm) | 450 |
| Max print repeat (mm) | 1100 |
| Unwinder type | Turret automatic |
| Rewinder type | Turret automatic |
| Drying | 2 zones - 4 fans - 5 mt tunnel - 2 gas burners - automatic recirculation system with LEL control |
| Videocamera | Yes |
| Corona treatment | yes |
| Web guides | Yes in and out |
| Vyscosity control | Yes |
| Washing system | Yes automatic |
| Inking system | Closed chamber doctor blades |
| Anilox | 12 ceramic anilox sleeves |
| Print Sleeves | 80 |
